Sony HAP-S1 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HAP-S1
122
< SWITCH >
S5001 1-762-875-21 SWITCH, KEYBOARD (BACK)
S5002 1-762-875-21 SWITCH, KEYBOARD (HOME)
S5003 1-762-875-21 SWITCH, KEYBOARD (u)
*************************************************************
A-1989-167-A MAIN BOARD, COMPLETE (for SERVICE)
(US, CND) (See Note)
A-1989-168-A MAIN BOARD, COMPLETE (for SERVICE)
(AEP, UK) (See Note)
********************
< CAPACITOR >
C101 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C102 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C103 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C104 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C105 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C106 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C111 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C112 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C113 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C114 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C115 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C116 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C117 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C118 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C119 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C120 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C121 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C123 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C124 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C125 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C126 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C127 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C128 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C129 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C130 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C131 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C132 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C137 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C138 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C139 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C140 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C141 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C142 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C144 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C145 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C146 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C147 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C148 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C150 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C151 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C152 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C153 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C154 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C155 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C156 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C157 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C159 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C174 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C180 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C182 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C183 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C184 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C185 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C186 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C187 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C188 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
* C189 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C190 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C192 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C193 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
* C194 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C201 1-116-711-11 CERAMIC CHIP 22uF 20% 16V
* C202 1-116-735-11 CERAMIC CHIP 1uF 10% 16V
C203 1-116-711-11 CERAMIC CHIP 22uF 20% 16V
C204 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C205 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C206 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C207 1-116-711-11 CERAMIC CHIP 22uF 20% 16V
C208 1-116-711-11 CERAMIC CHIP 22uF 20% 16V
C209 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C210 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C211 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
* C212 1-118-401-11 CERAMIC CHIP 0.0015uF 10% 50V
C216 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C217 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C219 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C220 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C221 1-116-151-11 CERAMIC CHIP 0.001uF 2% 50V
C222 1-116-151-11 CERAMIC CHIP 0.001uF 2% 50V
C223 1-116-151-11 CERAMIC CHIP 0.001uF 2% 50V
C224 1-116-151-11 CERAMIC CHIP 0.001uF 2% 50V
C229 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C230 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C231 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C233 1-165-492-21 ELECT CHIP 100uF 20% 10V
C235 1-116-151-11 CERAMIC CHIP 0.001uF 2% 50V
C236 1-116-151-11 CERAMIC CHIP 0.001uF 2% 50V
C237 1-116-711-11 CERAMIC CHIP 22uF 20% 16V
C238 1-116-711-11 CERAMIC CHIP 22uF 20% 16V
C240 1-116-745-11 CERAMIC CHIP 0.22uF 10% 6.3V
C241 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
* C301 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C302 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C303 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C304 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C305 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C306 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C307 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C308 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C309 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C310 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C311 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
* C312 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C313 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C314 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C315 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
* C316 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C317 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
KEY JOG MAIN
Note: When the complete MAIN board is replaced, refer to “NOTE OF REPLACING THE COMPLETE
MAIN BOARD” and “CHECKING METHOD OF NETWORK CONNECTION” on page 5.

Sony HAP-S1 Specifications

General

Product color	Silver
Audio formats supported	AAC, AIFF, ALAC, FLAC, LPCM, MP3, WAV, WMA
Impedance	16 Ω
Frequency range	10 - 100000 Hz
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Channels quantity	2 channels
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Automatic synchronization	You don't have to change personal settings when first connecting your device. Your device is automatically synchronized with the settings of your car, so once you have done it for the car, that's it!
Storage media type	HDD
Total storage capacity	500 GB
HDCP	No
Headphone outputs	1
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Display diagonal	4.3 \

Weight and Dimensions

Width	- mm
Weight	- g
