Sony HAP-S1 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HAP-S1
124
* ET009 1-780-408-11 TERMINAL, LUG
* ET010 1-780-408-11 TERMINAL, LUG
< FERRITE BEAD >
FB101 1-400-462-21 FERRITE, EMI (SMD) (1005)
FB401 1-400-462-21 FERRITE, EMI (SMD) (1005)
FB601 1-400-462-21 FERRITE, EMI (SMD) (1005)
FB602 1-400-462-21 FERRITE, EMI (SMD) (1005)
FB1000 1-469-379-11 FERRITE, EMI (SMD) (2012)
FB1001 1-469-379-11 FERRITE, EMI (SMD) (2012)
< FILTER >
FL201 1-234-939-21 FILTER, EMI REMOVAL (SMD)
FL400 1-234-939-21 FILTER, EMI REMOVAL (SMD)
FL401 1-234-939-21 FILTER, EMI REMOVAL (SMD)
FL501 1-234-939-21 FILTER, EMI REMOVAL (SMD)
FL701 1-234-939-21 FILTER, EMI REMOVAL (SMD)
< IC >
IC101 (Not supplied) IC MCIMX6D5EYM10AC (See Note)
IC201 6-717-694-01 IC BU33TD3WG-TR
IC202 6-716-554-11 IC BD9329AEFJ-E2
IC203 6-718-705-01 IC TPS54295PWPR
IC204 6-715-874-01 IC MM3464A33NRE
IC205 6-713-333-01 IC PST8429UL
IC301 (Not supplied) IC H5TQ1G63EFR-H9CR (See Note)
IC302 (Not supplied) IC H5TQ1G63EFR-H9CR (See Note)
IC401 6-713-333-01 IC PST8429UL
IC501 (Not supplied) IC KLM4G1FE3B-B001T03 (See Note)
IC602 (Not supplied) IC AR8035-AL1A (See Note)
IC701 6-717-669-01 IC TB62752AFUG (O, EL)
IC1001 6-715-164-01 IC TPS2553DBVR
< COIL >
L201 1-457-871-11 CHOKE COIL 2.2uH
L202 1-457-871-11 CHOKE COIL 2.2uH
L203 1-460-576-11 COIL, CHOKE 4.7uH
L601 1-400-790-21 INDUCTOR 4.7uH
L602 1-460-653-21 COIL, COMMON MODE CHOKE
L603 1-460-653-21 COIL, COMMON MODE CHOKE
L604 1-460-653-21 COIL, COMMON MODE CHOKE
L605 1-460-653-21 COIL, COMMON MODE CHOKE
L701 1-460-586-11 COIL, CHOKE 22uH
L1001 1-460-652-21 COIL, COMMON MODE CHOKE
L1002 1-460-652-21 COIL, COMMON MODE CHOKE
< TRANSISTOR >
Q201 8-729-928-90 TRANSISTOR DTC114EE
Q202 8-729-928-90 TRANSISTOR DTC114EE
Q203 8-729-928-36 TRANSISTOR DTA114EE
Q701 6-552-621-01 FET SSM3K37MFV, L3SOF
Q702 6-552-621-01 FET SSM3K37MFV, L3SOF
Q703 6-552-621-01 FET SSM3K37MFV, L3SOF
Q704 6-552-029-01 FET MCH3377-S-TL-E
Q1001 6-552-621-01 FET SSM3K37MFV, L3SOF
Q1002 6-552-029-01 FET MCH3377-S-TL-E
< RESISTOR/FERRITE BEAD >
R103 1-218-990-81 SHORT CHIP 0
R104 1-218-990-81 SHORT CHIP 0
R105 1-218-990-81 SHORT CHIP 0
R106 1-218-990-81 SHORT CHIP 0
R108 1-218-990-81 SHORT CHIP 0
R109 1-218-990-81 SHORT CHIP 0
R116 1-218-990-81 SHORT CHIP 0
R117 1-218-990-81 SHORT CHIP 0
R201 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R202 1-208-647-11 METAL CHIP 33 0.5% 1/16W
R203 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R204 1-218-990-81 SHORT CHIP 0
R206 1-218-990-81 SHORT CHIP 0
R207 1-208-905-11 METAL CHIP 5.6K 0.5% 1/16W
R208 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R209 1-250-455-11 METAL CHIP 22 1% 1/16W
* R210 1-250-523-11 METAL CHIP 15K 1% 1/16W
R211 1-218-990-81 SHORT CHIP 0
R212 1-250-495-11 METAL CHIP 1K 1% 1/16W
R213 1-250-495-11 METAL CHIP 1K 1% 1/16W
R215 1-250-495-11 METAL CHIP 1K 1% 1/16W
R217 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R218 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R224 1-250-519-11 METAL CHIP 10K 1% 1/16W
R225 1-218-990-81 SHORT CHIP 0
R242 1-216-864-11 SHORT CHIP 0
R243 1-216-864-11 SHORT CHIP 0
R244 1-218-990-81 SHORT CHIP 0
R248 1-218-990-81 SHORT CHIP 0
R253 1-218-990-81 SHORT CHIP 0
R254 1-218-990-81 SHORT CHIP 0
* R256 1-250-501-11 METAL CHIP 1.8K 1% 1/16W
R257 1-218-990-81 SHORT CHIP 0
R258 1-218-990-81 SHORT CHIP 0
R259 1-218-990-81 SHORT CHIP 0
R261 1-218-990-81 SHORT CHIP 0
R301 1-250-495-11 METAL CHIP 1K 1% 1/16W
R302 1-250-495-11 METAL CHIP 1K 1% 1/16W
R303 1-218-965-11 METAL CHIP 10K 5% 1/16W
R304 1-218-990-81 SHORT CHIP 0
R305 1-218-990-81 SHORT CHIP 0
* R306 1-250-480-11 METAL CHIP 240 1% 1/16W
* R307 1-250-480-11 METAL CHIP 240 1% 1/16W
R308 1-218-945-11 METAL CHIP 220 5% 1/16W
* R309 1-250-480-11 METAL CHIP 240 1% 1/16W
R310 1-218-945-11 METAL CHIP 220 5% 1/16W
R404 1-220-804-11 METAL CHIP 2.2M 5% 1/16W
R406 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R409 1-245-604-11 METAL CHIP 10M 5% 1/16W
R410 1-218-990-81 SHORT CHIP 0
R411 1-218-990-81 SHORT CHIP 0
R413 1-218-965-11 METAL CHIP 10K 5% 1/16W
R417 1-218-965-11 METAL CHIP 10K 5% 1/16W
R418 1-218-965-11 METAL CHIP 10K 5% 1/16W
R422 1-218-965-11 METAL CHIP 10K 5% 1/16W
R425 1-245-604-11 METAL CHIP 10M 5% 1/16W
R426 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R429 1-250-471-11 METAL CHIP 100 1% 1/16W
R430 1-250-471-11 METAL CHIP 100 1% 1/16W
R431 1-218-990-81 SHORT CHIP 0
R432 1-218-990-81 SHORT CHIP 0
Note: IC101, IC301, IC302, IC501 and IC602 on the MAIN board cannot exchange with
single. When these parts are damaged, exchange the complete mounted board.
MAIN
