Sony HAP-S1 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HAP-S1
125
R454 1-218-990-81 SHORT CHIP 0
R456 1-218-990-81 SHORT CHIP 0
R457 1-218-990-81 SHORT CHIP 0
R458 1-218-990-81 SHORT CHIP 0
R463 1-250-471-11 METAL CHIP 100 1% 1/16W
R466 1-218-990-81 SHORT CHIP 0
R468 1-218-990-81 SHORT CHIP 0
R469 1-218-990-81 SHORT CHIP 0
R470 1-250-471-11 METAL CHIP 100 1% 1/16W
R471 1-250-471-11 METAL CHIP 100 1% 1/16W
R472 1-250-471-11 METAL CHIP 100 1% 1/16W
R473 1-250-471-11 METAL CHIP 100 1% 1/16W
R501 1-218-965-11 METAL CHIP 10K 5% 1/16W
R502 1-218-934-11 METAL CHIP 27 5% 1/16W
R503 1-250-455-11 METAL CHIP 22 1% 1/16W
R504 1-250-455-11 METAL CHIP 22 1% 1/16W
R505 1-250-455-11 METAL CHIP 22 1% 1/16W
R506 1-250-455-11 METAL CHIP 22 1% 1/16W
R507 1-250-455-11 METAL CHIP 22 1% 1/16W
R508 1-250-455-11 METAL CHIP 22 1% 1/16W
R509 1-218-990-81 SHORT CHIP 0
R536 1-218-990-81 SHORT CHIP 0
R537 1-218-990-81 SHORT CHIP 0
R538 1-218-990-81 SHORT CHIP 0
R539 1-218-990-81 SHORT CHIP 0
R541 1-218-990-81 SHORT CHIP 0
R601 1-218-990-81 SHORT CHIP 0
R602 1-218-990-81 SHORT CHIP 0
R605 1-218-933-11 METAL CHIP 22 5% 1/16W
R606 1-218-990-81 SHORT CHIP 0
R607 1-218-990-81 SHORT CHIP 0
R610 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R611 1-218-990-81 SHORT CHIP 0
R612 1-218-933-11 METAL CHIP 22 5% 1/16W
R614 1-218-990-81 SHORT CHIP 0
R615 1-218-990-81 SHORT CHIP 0
R616 1-218-990-81 SHORT CHIP 0
R618 1-218-965-11 METAL CHIP 10K 5% 1/16W
R621 1-218-990-81 SHORT CHIP 0
R623 1-218-965-11 METAL CHIP 10K 5% 1/16W
R624 1-218-965-11 METAL CHIP 10K 5% 1/16W
R626 1-218-990-81 SHORT CHIP 0
R627 1-218-965-11 METAL CHIP 10K 5% 1/16W
* R630 1-250-501-11 METAL CHIP 1.8K 1% 1/16W
R632 1-250-487-11 METAL CHIP 470 1% 1/16W
R633 1-250-471-11 METAL CHIP 100 1% 1/16W
R637 1-218-990-81 SHORT CHIP 0
R638 1-218-965-11 METAL CHIP 10K 5% 1/16W
* R639 1-250-589-11 METAL CHIP 75 1% 1/10W
* R640 1-250-589-11 METAL CHIP 75 1% 1/10W
* R641 1-250-589-11 METAL CHIP 75 1% 1/10W
* R642 1-250-589-11 METAL CHIP 75 1% 1/10W
R648 1-250-535-11 METAL CHIP 47K 1% 1/16W
R649 1-250-535-11 METAL CHIP 47K 1% 1/16W
R651 1-218-990-81 SHORT CHIP 0
R654 1-218-990-81 SHORT CHIP 0
R655 1-218-965-11 METAL CHIP 10K 5% 1/16W
R657 1-218-990-81 SHORT CHIP 0
R701 1-218-990-81 SHORT CHIP 0
R702 1-218-990-81 SHORT CHIP 0
R705 1-218-990-81 SHORT CHIP 0
R726 1-250-455-11 METAL CHIP 22 1% 1/16W
* R727 1-250-479-11 METAL CHIP 220 1% 1/16W
R728 1-250-467-11 METAL CHIP 68 1% 1/16W
R729 1-218-990-81 SHORT CHIP 0
R730 1-218-990-81 SHORT CHIP 0
R733 1-218-990-81 SHORT CHIP 0
R734 1-218-985-11 METAL CHIP 470K 5% 1/16W
R739 1-218-990-81 SHORT CHIP 0
R741 1-218-990-81 SHORT CHIP 0
R742 1-218-990-81 SHORT CHIP 0
R743 1-218-990-81 SHORT CHIP 0
R749 1-218-990-81 SHORT CHIP 0
R750 1-218-990-81 SHORT CHIP 0
R751 1-218-990-81 SHORT CHIP 0
R752 1-400-462-21 FERRITE, EMI (SMD) (1005)
R755 1-218-990-81 SHORT CHIP 0
R756 1-218-990-81 SHORT CHIP 0
R757 1-218-990-81 SHORT CHIP 0
R758 1-218-990-81 SHORT CHIP 0
R761 1-218-965-11 METAL CHIP 10K 5% 1/16W
R762 1-218-990-81 SHORT CHIP 0
R764 1-218-965-11 METAL CHIP 10K 5% 1/16W
R801 1-250-495-11 METAL CHIP 1K 1% 1/16W
R802 1-250-495-11 METAL CHIP 1K 1% 1/16W
R804 1-250-495-11 METAL CHIP 1K 1% 1/16W
R806 1-250-495-11 METAL CHIP 1K 1% 1/16W
R807 1-250-495-11 METAL CHIP 1K 1% 1/16W
R813 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R814 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R815 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R820 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R821 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R822 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R823 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R836 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R839 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R845 1-218-990-81 SHORT CHIP 0
R846 1-218-990-81 SHORT CHIP 0
R853 1-218-990-81 SHORT CHIP 0
R854 1-218-990-81 SHORT CHIP 0
R901 1-218-990-81 SHORT CHIP 0
R1001 1-218-990-81 SHORT CHIP 0
R1002 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1008 1-218-990-81 SHORT CHIP 0
R1010 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1011 1-218-985-11 METAL CHIP 470K 5% 1/16W
R1013 1-250-519-11 METAL CHIP 10K 1% 1/16W
R1014 1-250-519-11 METAL CHIP 10K 1% 1/16W
R1015 1-218-965-11 METAL CHIP 10K 5% 1/16W
* R1017 1-250-477-11 METAL CHIP 180 1% 1/16W
R1018 1-250-455-11 METAL CHIP 22 1% 1/16W
R1019 1-250-455-11 METAL CHIP 22 1% 1/16W
R1020 1-218-990-81 SHORT CHIP 0
R1021 1-218-990-81 SHORT CHIP 0
R1023 1-218-990-81 SHORT CHIP 0
R1024 1-218-990-81 SHORT CHIP 0
R1026 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1027 1-218-965-11 METAL CHIP 10K 5% 1/16W
MAIN

Sony HAP-S1 Specifications

General

Product color	Silver
Audio formats supported	AAC, AIFF, ALAC, FLAC, LPCM, MP3, WAV, WMA
Impedance	16 Ω
Frequency range	10 - 100000 Hz
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Channels quantity	2 channels
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Automatic synchronization	You don't have to change personal settings when first connecting your device. Your device is automatically synchronized with the settings of your car, so once you have done it for the car, that's it!
Storage media type	HDD
Total storage capacity	500 GB
HDCP	No
Headphone outputs	1
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Display diagonal	4.3 \
