Sony HAP-S1 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HAP-S1
126
< COMPOSITION CIRCUIT BLOCK >
RB601 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB602 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB701 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB702 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB703 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB704 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB705 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB706 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB801 1-234-378-21 RES, NETWORK 10K (1005X4)
RB802 1-234-378-21 RES, NETWORK 10K (1005X4)
RB810 1-234-378-21 RES, NETWORK 10K (1005X4)
RB811 1-234-378-21 RES, NETWORK 10K (1005X4)
RB812 1-234-378-21 RES, NETWORK 10K (1005X4)
RB813 1-234-378-21 RES, NETWORK 10K (1005X4)
RB814 1-234-378-21 RES, NETWORK 10K (1005X4)
RB815 1-234-378-21 RES, NETWORK 10K (1005X4)
< TRANSFORMER >
T601 1-697-310-11 PULSE TRANSFORMER
T602 1-697-310-11 PULSE TRANSFORMER
T603 1-697-310-11 PULSE TRANSFORMER
T604 1-697-310-11 PULSE TRANSFORMER
< VIBRATOR >
X401 1-814-404-11 QUARTZ CRYSTAL UNITS (24 MHz)
X403 1-814-273-11 QUARTZ CRYSTAL UNIT (32.768 kHz)
X601 1-814-242-11 VIBRATOR, CRYSTAL (25 MHz)
*************************************************************
A-1974-810-A PENC BOARD, COMPLETE
*********************
< CAPACITOR >
C5051 1-118-385-11 CERAMIC CHIP 0.001uF 10% 50V
C5053 1-118-385-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN5301 1-569-775-21 PIN, CONNECTOR (SMD) 5P
< ROTARY ENCODER >
EN5005 1-487-023-22 ROTARY ENCODER (PUSH ENTER)
< RESISTOR >
R5119 1-216-809-11 METAL CHIP 100 5% 1/10W
R5120 1-216-809-11 METAL CHIP 100 5% 1/10W
R5574 1-216-833-11 METAL CHIP 10K 5% 1/10W
*************************************************************
POWER KEY BOARD
****************
< CONNECTOR >
CN1002 1-580-057-11 PIN, CONNECTOR (SMD) 4P
< LED >
D1002 6-503-970-01 LED SELU5423E-STP15 (
?
/1)
< SWITCH >
S1029 1-762-875-21 SWITCH, KEYBOARD (
?
/1)
*************************************************************
A-1945-077-A SPTM BOARD, COMPLETE (AEP, UK)
A-1945-078-A SPTM BOARD, COMPLETE (US, CND)
*********************
< CAPACITOR >
C700 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
C701 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C702 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
C703 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
* CN701 1-564-216-00 PIN, CONNECTOR (3.96 mm PITCH) 5P
< COIL >
L700 1-411-906-11 COIL, AIR-CORE
L701 1-411-906-11 COIL, AIR-CORE
< RESISTOR >
0 R700 1-249-393-91 CARBON 10 5% 1/4W F
0 R701 1-249-393-91 CARBON 10 5% 1/4W F
0 R702 1-249-389-91 CARBON 4.7 5% 1/4W F
0 R703 1-249-389-91 CARBON 4.7 5% 1/4W F
< TERMINAL >
0 TB700 1-854-056-11 TERMINAL BOARD, SPEAKER 2P (SPEAKERS R)
0 TB701 1-854-057-11 TERMINAL BOARD, SPEAKER 2P (SPEAKERS L)
*************************************************************
A-1945-084-A STANBY BOARD, COMPLETE (AEP, UK)
A-1945-085-A STANBY BOARD, COMPLETE (US, CND)
***********************
< CAPACITOR >
C1901 1-128-991-21 ELECT CHIP 10uF 20% 50V
C1903 1-126-948-11 ELECT 100uF 20% 35V
C1906 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1907 1-114-329-11 CERAMIC CHIP 0.47uF 10% 50V
0 C1909 1-118-661-11 CERAMIC 0.01uF 20% 250V
< CONNECTOR >
CN1901 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
0 * CN1903 1-565-792-11 PIN, CONNECTOR (3.96 mm PITCH) 2P
0 * CN1904 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
< DIODE >
D1901 8-719-053-18 DIODE 1SR154-400TE-25
D1902 8-719-053-18 DIODE 1SR154-400TE-25
D1903 8-719-053-18 DIODE 1SR154-400TE-25
D1904 8-719-053-18 DIODE 1SR154-400TE-25
D1905 6-502-961-01 DIODE DA2J10100L
D1906 6-502-961-01 DIODE DA2J10100L
D1907 6-502-961-01 DIODE DA2J10100L
< FUSE HOLDER >
0 FH1903 1-533-313-11 FUSE HOLDER
0 FH1904 1-533-313-11 FUSE HOLDER
MAIN PENC POWER KEY SPTM STANBY

Sony HAP-S1 Specifications

General

Product color	Silver
Audio formats supported	AAC, AIFF, ALAC, FLAC, LPCM, MP3, WAV, WMA
Impedance	16 Ω
Frequency range	10 - 100000 Hz
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Channels quantity	2 channels
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Automatic synchronization	You don't have to change personal settings when first connecting your device. Your device is automatically synchronized with the settings of your car, so once you have done it for the car, that's it!
Storage media type	HDD
Total storage capacity	500 GB
HDCP	No
Headphone outputs	1
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Display diagonal	4.3 \
