Sony HAP-S1 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HAP-S1
128
< TRANSISTOR >
Q1001 6-553-268-01 TRANSISTOR PDTC114ET
Q1003 6-553-267-01 TRANSISTOR 2PB709ART
< RESISTOR >
R1003 1-216-809-11 METAL CHIP 100 5% 1/10W
R1005 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1007 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1009 1-216-176-11 METAL CHIP 120 5% 1/8W
R5011 1-216-295-91 SHORT CHIP 0
R5016 1-218-941-81 METAL CHIP 100 5% 1/16W
R5018 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5019 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5020 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5021 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5024 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5025 1-218-941-81 METAL CHIP 100 5% 1/16W
R5026 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5027 1-218-941-81 METAL CHIP 100 5% 1/16W
R5028 1-218-941-81 METAL CHIP 100 5% 1/16W
R5029 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5030 1-218-941-81 METAL CHIP 100 5% 1/16W
R5031 1-218-941-81 METAL CHIP 100 5% 1/16W
R5032 1-218-941-81 METAL CHIP 100 5% 1/16W
R5033 1-218-941-81 METAL CHIP 100 5% 1/16W
R5034 1-218-941-81 METAL CHIP 100 5% 1/16W
R5035 1-218-941-81 METAL CHIP 100 5% 1/16W
R5036 1-218-941-81 METAL CHIP 100 5% 1/16W
R5037 1-218-941-81 METAL CHIP 100 5% 1/16W
R5039 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5040 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5041 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5042 1-218-941-81 METAL CHIP 100 5% 1/16W
R5043 1-218-941-81 METAL CHIP 100 5% 1/16W
R5045 1-218-941-81 METAL CHIP 100 5% 1/16W
R5046 1-218-941-81 METAL CHIP 100 5% 1/16W
R5047 1-218-941-81 METAL CHIP 100 5% 1/16W
R5048 1-218-941-81 METAL CHIP 100 5% 1/16W
R5049 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R5050 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R5051 1-218-941-81 METAL CHIP 100 5% 1/16W
R5052 1-218-941-81 METAL CHIP 100 5% 1/16W
R5053 1-218-941-81 METAL CHIP 100 5% 1/16W
R5054 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5055 1-218-941-81 METAL CHIP 100 5% 1/16W
R5056 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5057 1-218-941-81 METAL CHIP 100 5% 1/16W
R5058 1-218-941-81 METAL CHIP 100 5% 1/16W
R5059 1-218-941-81 METAL CHIP 100 5% 1/16W
R5060 1-218-941-81 METAL CHIP 100 5% 1/16W
R5061 1-218-941-81 METAL CHIP 100 5% 1/16W
R5062 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5063 1-218-941-81 METAL CHIP 100 5% 1/16W
R5064 1-218-941-81 METAL CHIP 100 5% 1/16W
R5065 1-218-941-81 METAL CHIP 100 5% 1/16W
R5066 1-218-941-81 METAL CHIP 100 5% 1/16W
R5067 1-218-941-81 METAL CHIP 100 5% 1/16W
R5068 1-218-941-81 METAL CHIP 100 5% 1/16W
R5072 1-218-941-81 METAL CHIP 100 5% 1/16W
R5074 1-218-941-81 METAL CHIP 100 5% 1/16W
R5075 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5076 1-218-941-81 METAL CHIP 100 5% 1/16W
R5077 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R5078 1-218-941-81 METAL CHIP 100 5% 1/16W
R5079 1-218-941-81 METAL CHIP 100 5% 1/16W
R5080 1-218-941-81 METAL CHIP 100 5% 1/16W
R5081 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5087 1-218-941-81 METAL CHIP 100 5% 1/16W
R5088 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5089 1-218-941-81 METAL CHIP 100 5% 1/16W
R5090 1-218-941-81 METAL CHIP 100 5% 1/16W
R5091 1-218-941-81 METAL CHIP 100 5% 1/16W
R5092 1-218-941-81 METAL CHIP 100 5% 1/16W
R5093 1-218-941-81 METAL CHIP 100 5% 1/16W
R5094 1-218-941-81 METAL CHIP 100 5% 1/16W
R5096 1-218-941-81 METAL CHIP 100 5% 1/16W
R5097 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5098 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5099 1-218-941-81 METAL CHIP 100 5% 1/16W
R5100 1-218-941-81 METAL CHIP 100 5% 1/16W
R5102 1-218-941-81 METAL CHIP 100 5% 1/16W
R5103 1-218-941-81 METAL CHIP 100 5% 1/16W
R5104 1-218-941-81 METAL CHIP 100 5% 1/16W
R5105 1-218-941-81 METAL CHIP 100 5% 1/16W
R5106 1-218-941-81 METAL CHIP 100 5% 1/16W
R5108 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R5111 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5112 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5113 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5114 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5115 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5116 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5122 1-218-941-81 METAL CHIP 100 5% 1/16W
R5123 1-218-941-81 METAL CHIP 100 5% 1/16W
R5124 1-218-941-81 METAL CHIP 100 5% 1/16W
R5129 1-218-941-81 METAL CHIP 100 5% 1/16W
R5130 1-218-941-81 METAL CHIP 100 5% 1/16W
R5131 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5132 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5136 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5137 1-218-941-81 METAL CHIP 100 5% 1/16W
R5139 1-218-990-81 SHORT CHIP 0
R5140 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5141 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5142 1-218-941-81 METAL CHIP 100 5% 1/16W
R5143 1-218-941-81 METAL CHIP 100 5% 1/16W
R5144 1-218-941-81 METAL CHIP 100 5% 1/16W
R5145 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5147 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5148 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5149 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5150 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5151 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5152 1-216-864-11 SHORT CHIP 0
R5153 1-216-864-11 SHORT CHIP 0
R5154 1-218-990-81 SHORT CHIP 0
R5155 1-216-797-11 METAL CHIP 10 5% 1/10W
R5158 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5159 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5162 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
U-COM
