Sony HAP-S1 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HAP-S1
129
R5163 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R5164 1-216-864-11 SHORT CHIP 0
R5165 1-218-941-81 METAL CHIP 100 5% 1/16W
R5166 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5167 1-216-797-11 METAL CHIP 10 5% 1/10W
R5168 1-216-864-11 SHORT CHIP 0
R5169 1-216-864-11 SHORT CHIP 0
R5171 1-216-295-91 SHORT CHIP 0
R5172 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5173 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5174 1-216-857-11 METAL CHIP 1M 5% 1/10W
R5178 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5179 1-216-837-11 METAL CHIP 22K 5% 1/10W
R5186 1-218-990-81 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB5001 1-234-373-21 RES, NETWORK 220 (1005X4)
< VIBRATOR >
X5001 1-781-646-21 VIBRATOR, CERAMIC (4 MHz)
*************************************************************
MISCELLANEOUS
**************
0 AC1 1-821-082-21 INLET, AC 2P
0 F902 1-532-388-33 FUSE (T 2 AL/250 V) (AEP, UK)
0 F902 1-532-504-33 FUSE (T 4 AL/250 V) (US, CND)
FC1 1-481-528-11 FILTER, CLAMP (FERRITE CORE)
FC2 1-481-528-11 FILTER, CLAMP (FERRITE CORE)
FC3 1-400-640-11 CORE, FERRITE
FC4 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
FC5 1-481-528-11 FILTER, CLAMP (FERRITE CORE)
FC6 1-500-082-11 CLAMP, SLEEVE FERRITE
FC7 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
FC8 1-500-082-11 CLAMP, SLEEVE FERRITE
FC9 1-500-082-11 CLAMP, SLEEVE FERRITE (AEP, UK)
FC10 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
FC11 1-400-640-11 CORE, FERRITE
FFC2 1-828-774-51 WIRE (FLAT TYPE) (24 CORE) (See Note 3)
FFC3 1-828-760-51 WIRE (FLAT TYPE) (22 CORE) (See Note 3)
FFC4 1-828-002-51 WIRE (FLAT TYPE) (17 CORE) (See Note 3)
0 HDD1 1-458-715-11 HDD/TSB-AQUARIUS-SLIM (500GB)
(Hard Disk Drive) (See Note 2)
LCD1 1-811-873-11 PANEL, LCD
0 M1 1-855-324-11 DC FAN
0 T1 1-697-296-11 TRANSFORMER, POWER (US, CND)
0 T1 1-697-304-11 TRANSFORMER, POWER (AEP, UK)
WBC1 1-458-601-31 CARD, WLAN/BT COMBO (See Note 1)
WR1 1-846-782-11 CABLE, COAXIAL (U.FL CONNECTOR) (for L-ch)
(See Note 1)
WR2 1-846-781-11 CABLE, COAXIAL (U.FL CONNECTOR) (for R-ch)
(See Note 1)
WR3 1-969-717-11 HARNESS (S-003)
WR4 1-969-719-11 HARNESS (E-001)
WR5 1-969-715-11 HARNESS (S-001)
*************************************************************
U-COM
ACCESSORIES
************
1-492-558-11 REMOTE COMMANDER RM-ANU183 (S)
(SILVER)
1-492-558-21 REMOTE COMMANDER RM-ANU183 (B) (BLACK)
1-837-633-12 POWER-SUPPLY CORD (AC power cord)
(US, CND)
1-839-699-12 CORD, POWER (AC power cord) (AEP)
1-846-946-11 CABLE, ETHERNET (LAN cable)
Note 1: When the WLAN/BT COMBO card (Ref. No. WBC1) and
coaxial (U.FL connector) cables (Ref. No. WR1, WR2) are
replaced, refer to “CHECKING METHOD OF NETWORK
CONNECTION” on page 5.
Note 3: Wires (fl at type) for service is straight.
When replacing wire (fl at type), install it after bending it in the
same form as that before replacement.
Note 2: When the hard disk drive (Ref. No. HDD1) is replaced, refer to
“NOTE OF REPLACING THE HARD DISK DRIVE (Ref. No.
HDD1)” on page 4.
