Sony HCD-FL3 - Page 108

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
108
HCD-FL3
GC HEAD (A) BOARD HEAD (B) BOARD IN/MIDIN SW
INIT/COUNT SW LOADING MOTOR MC
< VIBRATOR >
X201 1-577-358-21 VIBRATOR, CERAMIC (4MHz)
**************************************************************
A-2007-839-A HEAD (A) BOARD, COMPLETE
************************
< CONNECTOR >
* CN1 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
**************************************************************
A-2007-840-A HEAD (B) BOARD, COMPLETE
************************
< CONNECTOR >
CN2 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
**************************************************************
1-683-896-11 IN/MIDIN SW BOARD
*****************
< CONNECTOR >
* CN710 1-568-941-11 PIN, CONNECTOR 3P
< SWITCH >
S703 1-771-218-11 SWITCH, MICRO (MIDIN)
S704 1-771-218-11 SWITCH, MICRO (IN)
**************************************************************
1-683-897-11 INIT/COUNT SW BOARD
****************
< SWITCH >
S705 1-771-264-11 SWITCH, PUSH (DETECTION) (1 KEY) (INIT)
S706 1-771-264-11 SWITCH, PUSH (DETECTION) (1 KEY)
(COUNT)
**************************************************************
1-683-902-11 LOADING MOTOR BOARD
*********************
< CAPACITOR >
C703 1-162-306-11 CERAMIC 0.01uF 30% 16V
C704 1-126-964-11 ELECT 10uF 20% 50V
C712 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN713 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D702 8-719-109-85 DIODE MTZJ-T-72-5.1B
< IC >
IC702 8-759-598-69 IC BA6956AN
< RESISTOR >
R703 1-249-411-11 CARBON 330 5% 1/4W
R704 1-249-401-11 CARBON 47 5% 1/4W
**************************************************************
A-4728-413-A MC BOARD, COMPLETE (EXCEPT E2)
A-4729-484-A MC BOARD, COMPLETE (E2)
*******************
< CAPACITOR >
C110 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C111 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C112 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C116 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C117 1-126-917-11 ELECT 3300uF 20% 6.3V
C124 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C126 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C128 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C147 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C148 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C162 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C163 1-104-665-11 ELECT 100uF 20% 10V
C197 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C198 1-126-964-11 ELECT 10uF 20% 50V
C199 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C201 1-109-953-11 ELECT 2.2uF 20% 50V
C202 1-136-165-00 FILM 0.1uF 5% 50V
C203 1-136-165-00 FILM 0.1uF 5% 50V
C204 1-126-964-11 ELECT 10uF 20% 50V
C211 1-126-965-11 ELECT 22uF 20% 50V
C212 1-126-947-11 ELECT 47uF 20% 25V
C221 1-126-964-11 ELECT 10uF 20% 50V
C222 1-126-964-11 ELECT 10uF 20% 50V
C236 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C241 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C242 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C243 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C244 1-126-935-11 ELECT 470uF 20% 10V
C245 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C246 1-126-935-11 ELECT 470uF 20% 10V
C247 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C248 1-162-949-11 CERAMIC CHIP 47PF 5% 50V
C249 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C250 1-126-935-11 ELECT 470uF 20% 10V
C252 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C254 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C261 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C262 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN101 1-774-744-21 CONNECTOR, BOARD TO BOARD 18P
CN102 1-770-827-21 CONNECTOR, BOARD TO BOARD 16P
CN103 1-569-928-11 SOCKET, CONNECTOR 11P
CN104 1-569-935-11 SOCKET, CONNECTOR 19P
CN105 1-569-928-11 SOCKET, CONNECTOR 11P
CN106 1-569-937-11 SOCKET, CONNECTOR 21P
CN107 1-569-935-11 SOCKET, CONNECTOR 19P
CN109 1-569-934-11 SOCKET, CONNECTOR 17P
