Sony HCD-FL3 - Page 109

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
109
HCD-FL3
< DIODE >
D101 8-719-988-61 DIODE 1SS355TE-17
D102 8-719-988-61 DIODE 1SS355TE-17
D103 8-719-988-61 DIODE 1SS355TE-17
D104 8-719-988-61 DIODE 1SS355TE-17
D105 8-719-988-61 DIODE 1SS355TE-17
D106 8-719-988-61 DIODE 1SS355TE-17
D202 8-719-988-61 DIODE 1SS355TE-17
D203 8-719-988-61 DIODE 1SS355TE-17
D204 8-719-988-61 DIODE 1SS355TE-17
D205 8-719-988-61 DIODE 1SS355TE-17
D206 8-719-083-89 DIODE 11ES2-TB5
D207 8-719-083-89 DIODE 11ES2-TB5
D208 8-719-083-89 DIODE 11ES2-TB5
D211 8-719-988-61 DIODE 1SS355TE-17
D212 8-719-988-61 DIODE 1SS355TE-17
< GROUND TERMINAL >
* EP101 1-537-738-21 TERMINAL, EARTH
* EP201 1-537-738-21 TERMINAL, EARTH
< FERRITE BEAD/SHORT >
FB116 1-500-445-21 FERRITE 0uH
FB162 1-216-864-11 SHORT CHIP 0
FB199 1-216-864-11 SHORT CHIP 0
FB201 1-216-864-11 SHORT CHIP 0
FB202 1-216-864-11 SHORT CHIP 0
FB203 1-216-864-11 SHORT CHIP 0
< IC >
IC101 6-801-393-01 IC M30622MGN-A06FP
IC201 8-759-532-64 IC M62703SL-TP
IC202 8-759-263-43 IC TA78M12S
< SHORT >
JR101 1-216-864-11 SHORT CHIP 0
JR102 1-216-864-11 SHORT CHIP 0
JR103 1-216-864-11 SHORT CHIP 0
JR104 1-216-864-11 SHORT CHIP 0
JR190 1-216-864-11 SHORT CHIP 0
JR231 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q201 8-729-422-57 TRANSISTOR BN1A4M-TP
Q202 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q203 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q221 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q222 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q223 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q224 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q251 8-729-140-04 TRANSISTOR 2SB1116-TP-LK
Q252 8-729-116-02 TRANSISTOR BA1A4M-TP
Q253 8-729-140-04 TRANSISTOR 2SB1116-TP-LK
Q254 8-729-116-02 TRANSISTOR BA1A4M-TP
Q255 8-729-116-02 TRANSISTOR BA1A4M-TP
Q256 8-729-140-04 TRANSISTOR 2SB1116-TP-LK
Q257 8-729-116-02 TRANSISTOR BA1A4M-TP
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R102 1-216-809-11 METAL CHIP 100 5% 1/10W
R103 1-216-809-11 METAL CHIP 100 5% 1/10W
R104 1-216-809-11 METAL CHIP 100 5% 1/10W
R105 1-216-809-11 METAL CHIP 100 5% 1/10W
R106 1-216-809-11 METAL CHIP 100 5% 1/10W
R107 1-216-809-11 METAL CHIP 100 5% 1/10W
R109 1-216-833-11 METAL CHIP 10K 5% 1/10W
R111 1-216-851-11 METAL CHIP 330K 5% 1/10W
R113 1-216-864-11 SHORT CHIP 0
R117 1-216-833-11 METAL CHIP 10K 5% 1/10W
R118 1-216-809-11 METAL CHIP 100 5% 1/10W
R119 1-216-809-11 METAL CHIP 100 5% 1/10W
R120 1-216-809-11 METAL CHIP 100 5% 1/10W
R122 1-216-833-11 METAL CHIP 10K 5% 1/10W
R123 1-216-833-11 METAL CHIP 10K 5% 1/10W
R124 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R126 1-216-849-11 METAL CHIP 220K 5% 1/10W
R127 1-216-809-11 METAL CHIP 100 5% 1/10W
R128 1-216-845-11 METAL CHIP 100K 5% 1/10W
R129 1-216-809-11 METAL CHIP 100 5% 1/10W
R130 1-216-809-11 METAL CHIP 100 5% 1/10W
R132 1-216-809-11 METAL CHIP 100 5% 1/10W
R133 1-216-809-11 METAL CHIP 100 5% 1/10W
R134 1-216-809-11 METAL CHIP 100 5% 1/10W
R135 1-216-809-11 METAL CHIP 100 5% 1/10W
R136 1-216-833-11 METAL CHIP 10K 5% 1/10W
R137 1-216-809-11 METAL CHIP 100 5% 1/10W
R139 1-216-809-11 METAL CHIP 100 5% 1/10W
R140 1-216-809-11 METAL CHIP 100 5% 1/10W
R141 1-216-833-11 METAL CHIP 10K 5% 1/10W
R142 1-216-809-11 METAL CHIP 100 5% 1/10W
R143 1-216-809-11 METAL CHIP 100 5% 1/10W
R145 1-216-833-11 METAL CHIP 10K 5% 1/10W
R146 1-216-809-11 METAL CHIP 100 5% 1/10W
R147 1-216-864-11 SHORT CHIP 0
R148 1-216-864-11 SHORT CHIP 0
R149 1-216-809-11 METAL CHIP 100 5% 1/10W
R150 1-216-809-11 METAL CHIP 100 5% 1/10W
R153 1-216-809-11 METAL CHIP 100 5% 1/10W
R154 1-216-833-11 METAL CHIP 10K 5% 1/10W
R155 1-216-833-11 METAL CHIP 10K 5% 1/10W
R156 1-216-809-11 METAL CHIP 100 5% 1/10W
R157 1-216-809-11 METAL CHIP 100 5% 1/10W
R158 1-216-809-11 METAL CHIP 100 5% 1/10W
R159 1-216-809-11 METAL CHIP 100 5% 1/10W
R160 1-216-821-11 METAL CHIP 1K 5% 1/10W
R161 1-216-809-11 METAL CHIP 100 5% 1/10W
R162 1-216-833-11 METAL CHIP 10K 5% 1/10W
R163 1-216-833-11 METAL CHIP 10K 5% 1/10W
R164 1-216-833-11 METAL CHIP 10K 5% 1/10W
R165 1-216-809-11 METAL CHIP 100 5% 1/10W
R166 1-216-809-11 METAL CHIP 100 5% 1/10W
R167 1-216-809-11 METAL CHIP 100 5% 1/10W
R168 1-216-809-11 METAL CHIP 100 5% 1/10W
MC
