Sony HCD-FL3 - Page 110

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
110
HCD-FL3
MC MIC
R169 1-216-809-11 METAL CHIP 100 5% 1/10W
R170 1-216-809-11 METAL CHIP 100 5% 1/10W
R171 1-216-809-11 METAL CHIP 100 5% 1/10W
R172 1-216-809-11 METAL CHIP 100 5% 1/10W
R173 1-216-809-11 METAL CHIP 100 5% 1/10W
R174 1-216-809-11 METAL CHIP 100 5% 1/10W
R175 1-216-809-11 METAL CHIP 100 5% 1/10W
R176 1-216-809-11 METAL CHIP 100 5% 1/10W
R177 1-216-809-11 METAL CHIP 100 5% 1/10W
R178 1-216-809-11 METAL CHIP 100 5% 1/10W
R179 1-216-809-11 METAL CHIP 100 5% 1/10W
R180 1-216-809-11 METAL CHIP 100 5% 1/10W
R181 1-216-809-11 METAL CHIP 100 5% 1/10W
R182 1-216-809-11 METAL CHIP 100 5% 1/10W
R183 1-216-809-11 METAL CHIP 100 5% 1/10W
R184 1-216-809-11 METAL CHIP 100 5% 1/10W
R185 1-216-809-11 METAL CHIP 100 5% 1/10W
R186 1-216-809-11 METAL CHIP 100 5% 1/10W
R187 1-216-809-11 METAL CHIP 100 5% 1/10W
R188 1-216-809-11 METAL CHIP 100 5% 1/10W
R191 1-216-809-11 METAL CHIP 100 5% 1/10W
R192 1-216-809-11 METAL CHIP 100 5% 1/10W
R193 1-216-809-11 METAL CHIP 100 5% 1/10W
R194 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R195 1-216-821-11 METAL CHIP 1K 5% 1/10W
(E2, E51, MX, AR)
R196 1-216-864-11 SHORT CHIP 0
R197 1-216-833-11 METAL CHIP 10K 5% 1/10W
R198 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(E2, E51, MX, AR)
R198 1-216-864-11 SHORT CHIP 0 (SP, AUS)
R200 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R201 1-216-845-11 METAL CHIP 100K 5% 1/10W
R202 1-216-864-11 SHORT CHIP 0
R203 1-216-837-11 METAL CHIP 22K 5% 1/10W
R204 1-216-833-11 METAL CHIP 10K 5% 1/10W
R205 1-216-833-11 METAL CHIP 10K 5% 1/10W
R206 1-216-833-11 METAL CHIP 10K 5% 1/10W
R207 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R208 1-216-813-11 METAL CHIP 220 5% 1/10W
R209 1-216-833-11 METAL CHIP 10K 5% 1/10W
R221 1-216-833-11 METAL CHIP 10K 5% 1/10W
R222 1-216-833-11 METAL CHIP 10K 5% 1/10W
R223 1-216-833-11 METAL CHIP 10K 5% 1/10W
R224 1-216-833-11 METAL CHIP 10K 5% 1/10W
R251 1-216-821-11 METAL CHIP 1K 5% 1/10W
R252 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R253 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R254 1-216-821-11 METAL CHIP 1K 5% 1/10W
R255 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R256 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R257 1-216-841-11 METAL CHIP 47K 5% 1/10W
R258 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R259 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R260 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R261 1-216-841-11 METAL CHIP 47K 5% 1/10W
R262 1-216-841-11 METAL CHIP 47K 5% 1/10W
R263 1-216-841-11 METAL CHIP 47K 5% 1/10W
R264 1-216-841-11 METAL CHIP 47K 5% 1/10W
R265 1-216-821-11 METAL CHIP 1K 5% 1/10W
R266 1-216-841-11 METAL CHIP 47K 5% 1/10W
R267 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< VIBRATOR >
X101 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X102 1-781-107-21 VIBRATOR, SERAMIC (6MHz)
**************************************************************
A-4728-404-A MIC BOARD, COMPLETE
********************
< CAPACITOR >
C351 1-126-957-11 ELECT 0.22uF 20% 50V
C352 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C353 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C354 1-126-964-11 ELECT 10uF 20% 50V
C355 1-162-949-11 CERAMIC CHIP 47PF 5% 50V
C356 1-126-956-11 ELECT 0.1uF 20% 50V
C357 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C358 1-126-961-11 ELECT 2.2uF 20% 50V
C359 1-162-949-11 CERAMIC CHIP 47PF 5% 50V
C360 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C361 1-126-961-11 ELECT 2.2uF 20% 50V
C362 1-126-964-11 ELECT 10uF 20% 50V
C363 1-126-933-11 ELECT 100uF 20% 16V
C364 1-126-964-11 ELECT 10uF 20% 50V
C365 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C381 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN318 1-506-468-11 PIN, CONNECTOR 3P
< SHORT >
FB351 1-216-864-11 SHORT CHIP 0
< IC >
IC351 8-759-711-85 IC NJM4580E-D (T1)
< JACK >
J351 1-770-226-11 JACK (LARGE TYPE) (MIC)
< TRANSISTOR >
Q351 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R351 1-216-833-11 METAL CHIP 10K 5% 1/10W
R352 1-216-821-11 METAL CHIP 1K 5% 1/10W
R353 1-216-845-11 METAL CHIP 100K 5% 1/10W
R354 1-216-821-11 METAL CHIP 1K 5% 1/10W
R355 1-216-837-11 METAL CHIP 22K 5% 1/10W
R356 1-216-809-11 METAL CHIP 100 5% 1/10W
R357 1-216-833-11 METAL CHIP 10K 5% 1/10W
R358 1-216-847-11 METAL CHIP 150K 5% 1/10W
R359 1-216-809-11 METAL CHIP 100 5% 1/10W
R360 1-216-833-11 METAL CHIP 10K 5% 1/10W
