Sony HCD-FL3 - Page 111

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
111
HCD-FL3
R361 1-216-833-11 METAL CHIP 10K 5% 1/10W
R362 1-216-821-11 METAL CHIP 1K 5% 1/10W
R363 1-216-845-11 METAL CHIP 100K 5% 1/10W
R364 1-216-864-11 SHORT CHIP 0
< VARIABLE RESISTOR >
RV351 1-223-983-11 RES, VAR, CARBON 50K (MIC LEVEL)
**************************************************************
1-683-898-11 OUT/MIDOUT SW BOARD
********************
< CONNECTOR >
* CN709 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S701 1-771-218-11 SWITCH, MICRO (MIDOUT)
S702 1-771-218-11 SWITCH, MICRO (LID)
S708 1-771-218-11 SWITCH, MICRO (OUT)
**************************************************************
A-4728-401-A PANEL (L) BOARD, COMPLETE
****************
< CAPACITOR >
C301 1-126-947-11 ELECT 47uF 20% 10V
< LED >
D301 8-719-058-04 LED SEL5223S-TP15 (I/1)
D302 8-719-071-41 LED SELS5923C-TP15 (CD)
D303 8-719-071-41 LED SELS5923C-TP15 (TUNER/BAND)
D304 8-719-071-41 LED SELS5923C-TP15 (TAPE A/B)
< IC >
IC301 6-600-071-01 IC TSOP7000
< RESISTOR >
R301 1-216-813-11 METAL CHIP 220 5% 1/10W
R302 1-216-809-11 METAL CHIP 100 5% 1/10W
R303 1-216-809-11 METAL CHIP 100 5% 1/10W
R304 1-216-809-11 METAL CHIP 100 5% 1/10W
R305 1-216-819-11 METAL CHIP 680 5% 1/10W
R306 1-216-821-11 METAL CHIP 1K 5% 1/10W
R307 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R308 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R309 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R313 1-216-805-11 METAL CHIP 47 5% 1/10W
R314 1-216-805-11 METAL CHIP 47 5% 1/10W
R317 1-216-864-11 SHORT CHIP 0
R318 1-216-864-11 SHORT CHIP 0
R319 1-216-864-11 SHORT CHIP 0
R320 1-216-864-11 SHORT CHIP 0
< SWITCH >
S301 1-771-410-21 SWITCH, TACTILE (I/1)
S302 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S303 1-771-410-21 SWITCH, TACTILE (CD)
S304 1-771-410-21 SWITCH, TACTILE (TUNER/BAND)
S305 1-771-410-21 SWITCH, TACTILE (TAPE A/B)
S306 1-771-410-21 SWITCH, TACTILE (DIGITAL)
S307 1-771-410-21 SWITCH, TACTILE (MD (VIDEO))
**************************************************************
A-4728-403-A PANEL (R) BOARD, COMPLETE
*************************
< CAPACITOR >
C313 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< JACK >
J301 1-815-603-11 JACK (PHONES)
< RESISTOR >
R321 1-216-819-11 METAL CHIP 680 5% 1/10W
R322 1-216-821-11 METAL CHIP 1K 5% 1/10W
R323 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R324 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R325 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R326 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R327 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R328 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R329 1-216-819-11 METAL CHIP 680 5% 1/10W
R330 1-216-821-11 METAL CHIP 1K 5% 1/10W
R331 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R332 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
< SWITCH >
S311 1-771-410-21 SWITCH, TACTILE (DISC SELECT)
S312 1-771-410-21 SWITCH, TACTILE (Z)
S313 1-771-410-21 SWITCH, TACTILE (gG)
S314 1-771-410-21 SWITCH, TACTILE (X)
S315 1-771-410-21 SWITCH, TACTILE (x)
S316 1-771-410-21 SWITCH, TACTILE (.)
S317 1-771-410-21 SWITCH, TACTILE (>)
S318 1-771-410-21 SWITCH, TACTILE (– m)
S319 1-771-410-21 SWITCH, TACTILE (M +)
S320 1-771-410-21 SWITCH, TACTILE (GROOVE)
S321 1-771-410-21 SWITCH, TACTILE (EFFECT)
S322 1-771-410-21 SWITCH, TACTILE (CD SYNC, HI-DUB)
S323 1-771-410-21 SWITCH, TACTILE (REC, PAUSE/START)
S324 1-771-410-21 SWITCH, TACTILE (Z B)
**************************************************************
1-684-271-11 REGULATOR BOARD
****************
< CAPACITOR >
C870 1-115-867-11 ELECT 0.1uF 20% 50V
C871 1-115-867-11 ELECT 0.1uF 20% 50V
C872 1-115-867-11 ELECT 0.1uF 20% 50V
C873 1-115-867-11 ELECT 0.1uF 20% 50V
C878 1-126-791-11 ELECT 10uF 20% 16V
C879 1-126-791-11 ELECT 10uF 20% 16V
C880 1-126-791-11 ELECT 10uF 20% 16V
C881 1-126-791-11 ELECT 10uF 20% 16V
MIC OUT/MIDOUT SW PANEL (L) PANEL (R) REGULATOR
