Sony HCD-FL3 - Page 112

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
112
HCD-FL3
< IC >
IC801 6-701-760-01 IC UPC3504AHF
IC802 8-759-231-53 IC TA7805S
IC803 8-759-231-57 IC TA7810S
IC804 8-759-231-53 IC TA7805S
< TRANSISTOR >
Q864 8-729-040-20 TRANSISTOR RT1P137L-TP
Q865 8-729-116-02 TRANSISTOR BA1A4M-TP
< RESISTOR >
R873 1-216-864-11 SHORT CHIP 0
R887 1-216-809-11 METAL CHIP 100 5% 1/10W
**************************************************************
1-683-900-11 SENSOR 2 BOARD
****************
4-964-461-02 HOLDER (SENSOR)
< PHOTO TRANSISTOR >
Q703 8-729-921-53 PHOTO TRANSISTOR PT483F1
**************************************************************
1-683-899-11 SENSOR BOARD
*************
< CONNECTOR >
CN708 1-506-481-11 PIN, CONNECTOR 2P
< RESISTOR >
R711 1-249-412-11 CARBON 390 5% 1/4W
< DIODE >
D704 8-719-055-84 LED GL528VS1 (DISC IN DETECT SENSOR)
**************************************************************
A-4728-436-A SP RELAY BOARD, COMPLETE
************************
< CAPACITOR >
C1 1-126-947-11 ELECT 47uF 20% 16V
C2 1-130-483-00 MYLAR 0.01uF 5% 50V
C4 1-136-165-00 FILM 0.1uF 5% 50V
C6 1-126-960-11 ELECT 1uF 20% 50V
C7 1-126-961-11 ELECT 2.2uF 20% 50V
C8 1-126-964-11 ELECT 10uF 20% 50V
C9 1-126-960-11 ELECT 1uF 20% 50V
C10 1-126-964-11 ELECT 10uF 20% 50V
C11 1-126-960-11 ELECT 1uF 20% 50V
C12 1-126-960-11 ELECT 1uF 20% 50V
C13 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C14 1-126-964-11 ELECT 10uF 20% 50V
C16 1-126-933-11 ELECT 100uF 20% 16V
C17 1-126-964-11 ELECT 10uF 20% 50V
C21 1-164-392-11 CERAMIC CHIP 390PF 10% 50V
C22 1-164-392-11 CERAMIC CHIP 390PF 10% 50V
C23 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C24 1-137-427-11 MYLAR 120PF 5% 50V
C25 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C26 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C27 1-126-961-11 ELECT 2.2uF 20% 50V
C28 1-126-956-11 ELECT 0.1uF 20% 100V
C29 1-126-964-11 ELECT 10uF 20% 50V
C30 1-130-486-00 MYLAR 0.018uF 10% 50V
C31 1-130-481-00 MYLAR 0.0068uF 5% 50V
C32 1-130-481-00 MYLAR 0.0068uF 5% 50V
C33 1-130-485-00 MYLAR 0.015uF 5% 50V
C34 1-126-961-11 ELECT 2.2uF 20% 50V
C35 1-137-150-11 MYLAR 0.01uF 5% 100V
C40 1-126-960-11 ELECT 1uF 20% 50V
C41 1-126-960-11 ELECT 1uF 20% 50V
C42 1-126-960-11 ELECT 1uF 20% 50V
C43 1-126-935-11 ELECT 470uF 20% 10V
C44 1-104-665-11 ELECT 100uF 20% 10V
C45 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C46 1-130-483-00 MYLAR 0.01uF 5% 50V
C47 1-130-483-00 MYLAR 0.01uF 5% 50V
C48 1-126-964-11 ELECT 10uF 20% 50V
C49 1-126-965-11 ELECT 22uF 20% 50V
C51 1-126-947-11 ELECT 47uF 20% 16V
C52 1-130-483-00 MYLAR 0.01uF 5% 50V
C54 1-136-165-00 FILM 0.1uF 5% 50V
C56 1-126-960-11 ELECT 1uF 20% 50V
C57 1-126-961-11 ELECT 2.2uF 20% 50V
C63 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C71 1-164-392-11 CERAMIC CHIP 390PF 10% 50V
C72 1-164-392-11 CERAMIC CHIP 390PF 10% 50V
C73 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C74 1-137-427-11 MYLAR 120PF 5% 50V
C75 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C76 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C815 1-107-721-11 ELECT 4.7uF 20% 100V
C816 1-107-721-11 ELECT 4.7uF 20% 100V
C820 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C821 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C822 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C823 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C824 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C825 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C850 1-126-964-11 ELECT 10uF 20% 50V
C851 1-126-964-11 ELECT 10uF 20% 50V
C852 1-126-961-11 ELECT 2.2uF 20% 50V
C853 1-104-665-11 ELECT 100uF 20% 10V
C860 1-126-963-11 ELECT 4.7uF 20% 50V
C861 1-126-947-11 ELECT 47uF 20% 16V
C862 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C863 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C874 1-126-935-11 ELECT 470uF 20% 16V
C875 1-126-935-11 ELECT 470uF 20% 16V
C876 1-126-933-11 ELECT 100uF 20% 16V
C877 1-104-665-11 ELECT 100uF 20% 25V
C890 1-126-937-11 ELECT 4700uF 20% 16V
C891 1-130-483-00 MYLAR 0.01uF 5% 50V
C892 1-130-483-00 MYLAR 0.01uF 5% 50V
REGULATOR SENSOR 2 SENSOR SP RELAY
