Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
113
HCD-FL3
< CONNECTOR >
* CN601 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
* CN602 1-564-724-11 PIN, CONNECTOR (SMALL TYPE) 8P
CN801 1-784-039-21 CONNECTOR, BOARD TO BOARD 19P
CN803 1-573-844-11 CONNECTOR, BOARD TO BOARD 12P
CN804 1-766-715-21 CONNECTOR, BOARD TO BOARD 10P
CN805 1-774-743-21 CONNECTOR, BOARD TO BOARD 18P
CN806 1-770-828-21 CONNECTOR, BOARD TO BOARD 16P
* CN807 1-564-527-11 PLUG, CONNECTOR 12P
CN808 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
* CN809 1-564-518-11 PLUG, CONNECTOR 3P
< DIODE >
D801 8-719-988-61 DIODE 1SS355TE-17
D802 8-719-988-61 DIODE 1SS355TE-17
D803 8-719-988-61 DIODE 1SS355TE-17
D804 8-719-988-61 DIODE 1SS355TE-17
D805 8-719-988-61 DIODE 1SS355TE-17
D806 8-719-988-61 DIODE 1SS355TE-17
D807 8-719-988-61 DIODE 1SS355TE-17
D810 8-719-988-61 DIODE 1SS355TE-17
D850 8-719-988-61 DIODE 1SS355TE-17
D851 8-719-988-61 DIODE 1SS355TE-17
D860 8-719-988-61 DIODE 1SS355TE-17
D861 8-719-069-56 DIODE UDZSTE-176.2B
D862 8-719-978-33 DIODE UDZSTE-176.8B
D890 8-719-028-23 DIODE D3SBA20-4101
< IC >
IC1 6-702-130-01 IC HA12237F
IC2 8-759-143-54 IC uPC1330HA
IC3 8-759-100-96 IC NJM4558M-T1
< SHORT >
JR800 1-216-864-11 SHORT CHIP 0
JR802 1-216-864-11 SHORT CHIP 0
JR804 1-216-864-11 SHORT CHIP 0
JR805 1-216-864-11 SHORT CHIP 0
JR807 1-216-864-11 SHORT CHIP 0
JR808 1-216-864-11 SHORT CHIP 0
JR811 1-216-864-11 SHORT CHIP 0
JR815 1-216-864-11 SHORT CHIP 0
JR830 1-216-864-11 SHORT CHIP 0
< COIL >
L21 1-410-780-11 INDUCTOR 27mH
L40 1-414-193-41 INDUCTOR 220uH
L41 1-414-193-41 INDUCTOR 220uH
L71 1-410-780-11 INDUCTOR 27mH
< TRANSISTOR >
Q2 8-729-801-93 TRANSISTOR 2SD1387-34-TP
Q3 8-729-116-02 TRANSISTOR BA1A4M-TP
Q4 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q5 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q6 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q7 8-729-116-02 TRANSISTOR BA1A4M-TP
Q8 8-729-116-02 TRANSISTOR BA1A4M-TP
Q9 8-729-040-20 TRANSISTOR RT1P137L-TP
Q20 8-729-900-63 TRANSISTOR BN1F4M-TP
Q21 8-729-116-02 TRANSISTOR BA1A4M-TP
Q40 8-729-116-02 TRANSISTOR BA1A4M-TP
Q41 8-729-116-02 TRANSISTOR BA1A4M-TP
Q801 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q802 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q806 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q807 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q850 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q851 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q852 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q853 8-729-111-29 TRANSISTOR 2SD1616A-TP-LK
Q854 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q855 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q856 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q860 8-729-116-02 TRANSISTOR BA1A4M-TP
Q861 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q862 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q863 8-729-026-68 TRANSISTOR 2SD2525 (TP)
< RESISTOR >
R1 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R2 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5 1-216-841-11 METAL CHIP 47K 5% 1/10W
R6 1-216-837-11 METAL CHIP 22K 5% 1/10W
R7 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R9 1-216-837-11 METAL CHIP 22K 5% 1/10W
R11 1-216-809-11 METAL CHIP 100 5% 1/10W
R12 1-216-809-11 METAL CHIP 100 5% 1/10W
R13 1-216-809-11 METAL CHIP 100 5% 1/10W
R14 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R15 1-216-809-11 METAL CHIP 100 5% 1/10W
R17 1-216-857-11 METAL CHIP 1M 5% 1/10W
R18 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R19 1-216-837-11 METAL CHIP 22K 5% 1/10W
R20 1-216-809-11 METAL CHIP 100 5% 1/10W
R21 1-216-833-11 METAL CHIP 10K 5% 1/10W
R22 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R23 1-216-809-11 METAL CHIP 100 5% 1/10W
R25 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R26 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R27 1-216-836-11 METAL CHIP 18K 5% 1/10W
R28 1-216-836-11 METAL CHIP 18K 5% 1/10W
0 R29 1-219-787-17 FUSIBLE 5.6 5% 1/4W F
0 R30 1-219-787-17 FUSIBLE 5.6 5% 1/4W F
R31 1-216-837-11 METAL CHIP 22K 5% 1/10W
R32 1-216-813-11 METAL CHIP 220 5% 1/10W
R33 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R34 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R35 1-216-845-11 METAL CHIP 100K 5% 1/10W
R36 1-216-833-11 METAL CHIP 10K 5% 1/10W
R39 1-216-833-11 METAL CHIP 10K 5% 1/10W
R40 1-216-833-11 METAL CHIP 10K 5% 1/10W
R41 1-216-821-11 METAL CHIP 1K 5% 1/10W
SP RELAY
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
