Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
114
HCD-FL3
R42 1-216-821-11 METAL CHIP 1K 5% 1/10W
R43 1-216-861-11 METAL CHIP 2.2M 5% 1/10W
R44 1-216-835-11 METAL CHIP 15K 5% 1/10W
R45 1-216-835-11 METAL CHIP 15K 5% 1/10W
R46 1-216-833-11 METAL CHIP 10K 5% 1/10W
R47 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R48 1-216-837-11 METAL CHIP 22K 5% 1/10W
R49 1-216-833-11 METAL CHIP 10K 5% 1/10W
R50 1-216-833-11 METAL CHIP 10K 5% 1/10W
R51 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R52 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R54 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R55 1-216-841-11 METAL CHIP 47K 5% 1/10W
R56 1-216-837-11 METAL CHIP 22K 5% 1/10W
R58 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R68 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R71 1-216-833-11 METAL CHIP 10K 5% 1/10W
R72 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R90 1-216-864-11 SHORT CHIP 0
0 R815 1-215-891-11 METAL OXIDE 680 5% 2W F
0 R816 1-215-891-11 METAL OXIDE 680 5% 2W F
R820 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R821 1-216-833-11 METAL CHIP 10K 5% 1/10W
R822 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R823 1-216-833-11 METAL CHIP 10K 5% 1/10W
R824 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R825 1-216-833-11 METAL CHIP 10K 5% 1/10W
R826 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R827 1-216-833-11 METAL CHIP 10K 5% 1/10W
R828 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R829 1-216-833-11 METAL CHIP 10K 5% 1/10W
R830 1-216-833-11 METAL CHIP 10K 5% 1/10W
R831 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R832 1-216-833-11 METAL CHIP 10K 5% 1/10W
R833 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R836 1-216-809-11 METAL CHIP 100 5% 1/10W
R837 1-216-837-11 METAL CHIP 22K 5% 1/10W
R838 1-216-837-11 METAL CHIP 22K 5% 1/10W
R839 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R840 1-216-841-11 METAL CHIP 47K 5% 1/10W
R841 1-216-841-11 METAL CHIP 47K 5% 1/10W
R842 1-216-841-11 METAL CHIP 47K 5% 1/10W
R843 1-216-841-11 METAL CHIP 47K 5% 1/10W
R844 1-216-841-11 METAL CHIP 47K 5% 1/10W
R845 1-216-841-11 METAL CHIP 47K 5% 1/10W
R850 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R851 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R852 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R853 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R854 1-216-837-11 METAL CHIP 22K 5% 1/10W
R856 1-216-839-11 METAL CHIP 33K 5% 1/10W
R857 1-216-833-11 METAL CHIP 10K 5% 1/10W
R858 1-216-833-11 METAL CHIP 10K 5% 1/10W
R859 1-216-809-11 METAL CHIP 100 5% 1/10W
R860 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R861 1-216-841-11 METAL CHIP 47K 5% 1/10W
R862 1-216-837-11 METAL CHIP 22K 5% 1/10W
R863 1-216-837-11 METAL CHIP 22K 5% 1/10W
R864 1-216-849-11 METAL CHIP 220K 5% 1/10W
R865 1-216-841-11 METAL CHIP 47K 5% 1/10W
R866 1-216-843-11 METAL CHIP 68K 5% 1/10W
R867 1-216-843-11 METAL CHIP 68K 5% 1/10W
R868 1-216-843-11 METAL CHIP 68K 5% 1/10W
R869 1-216-841-11 METAL CHIP 47K 5% 1/10W
R870 1-216-843-11 METAL CHIP 68K 5% 1/10W
0 R874 1-215-863-11 METAL OXIDE 100 5% 1W F
0 R875 1-215-863-11 METAL OXIDE 100 5% 1W F
0 R876 1-215-863-11 METAL OXIDE 100 5% 1W F
0 R877 1-215-863-11 METAL OXIDE 100 5% 1W F
0 R878 1-215-863-11 METAL OXIDE 100 5% 1W F
0 R879 1-215-863-11 METAL OXIDE 100 5% 1W F
0 R880 1-215-863-11 METAL OXIDE 100 5% 1W F
0 R885 1-215-861-00 METAL OXIDE 47 5% 1W F
0 R886 1-215-861-00 METAL OXIDE 47 5% 1W F
R888 1-216-864-11 SHORT CHIP 0
< VARIABLE RESISTOR >
RV2 1-241-768-11 RES, ADJ, CARBON 220K
RV3 1-238-019-11 RES, ADJ, CARBON 47K
RV52 1-241-768-11 RES, ADJ, CARBON 220K
RV53 1-238-019-11 RES, ADJ, CARBON 47K
< RELAY >
RY801 1-755-421-11 RELAY
RY802 1-755-421-11 RELAY
RY803 1-755-421-11 RELAY
RY804 1-515-833-11 RELAY
RY805 1-515-833-11 RELAY
RY806 1-515-833-11 RELAY
RY807 1-755-421-11 RELAY
< TRANSFORMER >
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
< TERMINAL >
TM801 1-694-656-21 TERMINAL BOARD (6CH SPEAKER)
(SPEAKER IMPEDANCE USE 8–16Ω,
EXCEPT CENTER 16Ω)
**************************************************************
A-4676-864-A SUB TRANS BOARD, COMPLETE (AUS)
A-4676-874-A SUB TRANS BOARD, COMPLETE (MX)
A-4728-434-A SUB TRANS BOARD, COMPLETE (E2, E51, SP)
A-4730-238-A SUB TRANS BOARD, COMPLETE (AR)
****************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C901 1-104-665-11 ELECT 100uF 20% 10V
C902 1-126-767-11 ELECT 1000uF 20% 16V
C903 1-164-159-11 CERAMIC 0.1uF 50V
C904 1-113-925-11 CERAMIC 0.01uF 20% 250V
C905 1-126-964-11 ELECT 10uF 20% 50V
C906 1-164-159-11 CERAMIC 0.1uF 50V
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
SP RELAY SUB TRANS
To Next Page
