< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR (3.96MM PITCH) 2P
CN902 1-568-106-11 PIN, CONNECTOR (3.96MM PITCH) 4P
(E2, E51, SP)
* CN902 1-564-321-21 PIN, CONNECTOR (3.96MM PITCH) 2P
(AUS, AR, MX)
CN903 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
< DIODE >
D901 8-719-083-89 DIODE 11ES2N-TB5
D902 8-719-083-89 DIODE 11ES2N-TB5
D903 8-719-083-89 DIODE 11ES2N-TB5
D904 8-719-083-89 DIODE 11ES2N-TB5
D905 8-719-911-19 DIODE 1SS133T-72
D906 8-719-911-19 DIODE 1SS133T-72
< IC >
IC901 8-759-647-10 IC uPC2933HF
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R901 1-249-429-11 CARBON 10K 5% 1/4W
R902 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0 RY901 1-755-467-21 RELAY
< SWITCH >
0 S901 1-786-055-21 SELECTOR, VOLTAGE (E2, E51, SP)
< TRANSFORMER >
0 T901 1-437-677-11 TRANSFORMER, POWER
**************************************************************
A-4676-533-A SW BOARD, COMPLETE
*******************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20% 10V
< CONNECTOR >
CN1001 1-568-860-21 SOCKET, CONNECTOR 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS133T-72
D1002 8-719-911-19 DIODE 1SS133T-72
< IC >
IC1001 8-749-014-38 PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 PHOTO INTERRUPTER SG-264
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA-TP
< RESISTOR >
R1001 1-249-406-11 CARBON 120 5% 1/4W
R1002 1-249-406-11 CARBON 120 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-780-00 CARBON 7.5 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K
RV1002 1-241-785-11 RES, ADJ, CARBON 10K
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY) (DECK A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY) (DECK B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (DECK A HALF)
S1005 1-771-536-12 SWITCH, LEAF (DECK A REC)
S1006 1-771-333-11 SWITCH, LEAF (DECK B HALF)
S1009 1-771-536-12 SWITCH, LEAF (DECK B REC)
**************************************************************
1-684-198-11 TC DOOR BOARD
**************
< CONNECTOR >
CN319 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
< DIODE >
D309 8-719-988-61 DIODE 1SS355TE-17
D310 8-719-988-61 DIODE 1SS355TE-17
< SHORT >
JR214 1-216-864-11 SHORT CHIP 0
**************************************************************
1-684-199-11 TC DOOR SW BOARD
****************
< SWITCH >
S325 1-771-264-11 SWITCH, PUSH (DETECTION) (1 KEY)
(CASSETTE LID OPEN/CLOSE DETECT)
**************************************************************
1-684-200-11 TC SW (A) BOARD
****************
< RESISTOR >
R338 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S326 1-771-410-21 SWITCH, TACTILE (A Z)
**************************************************************
SUB TRANS SW TC DOOR TC DOOR SW TC SW (A)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
