Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
42
HCD-FL3
R761 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R762 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R763 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R764 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R765 1-216-864-11 SHORT CHIP 0
R767 1-216-864-11 SHORT CHIP 0
R768 1-216-809-11 RES-CHIP 100 5% 1/10W
R769 1-216-841-11 RES-CHIP 47K 5% 1/10W
R770 1-216-839-11 RES-CHIP 33K 5% 1/10W
R772 1-216-841-11 RES-CHIP 47K 5% 1/10W
R773 1-216-845-11 RES-CHIP 100K 5% 1/10W
R774 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R775 1-216-833-11 RES-CHIP 10K 5% 1/10W
R776 1-216-835-11 RES-CHIP 15K 5% 1/10W
R777 1-216-821-11 RES-CHIP 1K 5% 1/10W
R779 1-216-833-11 RES-CHIP 10K 5% 1/10W
R780 1-216-833-11 RES-CHIP 10K 5% 1/10W
R781 1-216-821-11 RES-CHIP 1K 5% 1/10W
R783 1-216-833-11 RES-CHIP 10K 5% 1/10W
R784 1-216-833-11 RES-CHIP 10K 5% 1/10W
R785 1-216-821-11 RES-CHIP 1K 5% 1/10W
R787 1-216-833-11 RES-CHIP 10K 5% 1/10W
R788 1-216-833-11 RES-CHIP 10K 5% 1/10W
R790 1-216-833-11 RES-CHIP 10K 5% 1/10W
R791 1-216-837-11 RES-CHIP 22K 5% 1/10W
R792 1-216-841-11 RES-CHIP 47K 5% 1/10W
R793 1-216-833-11 RES-CHIP 10K 5% 1/10W
R794 1-216-833-11 RES-CHIP 10K 5% 1/10W
< VIBRATOR >
X601 1-795-662-21 VIBRATOR, CERAMIC (13MHz)
X602 1-795-126-21 VIBRATOR, CRYSTAL (12.288MHz)
**************************************************************
A-4676-866-A FRONT REAR AMP BOARD, COMPLETE
(E2, E51, AR, MX)
A-4728-418-A FRONT REAR AMP BOARD, COMPLETE
(AUS, SP)
*******************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C401 1-126-964-11 ELECT 10uF 20% 50V
C402 1-162-290-31 CERAMIC 470PF 10% 50V
C403 1-162-282-31 CERAMIC 100PF 10% 50V
C404 1-126-947-11 ELECT 47uF 20% 10V
C405 1-136-165-00 FILM 0.1uF 5% 50V
C406 1-136-165-00 FILM 0.1uF 5% 50V
C407 1-126-965-11 ELECT 22uF 20% 50V
C408 1-126-965-11 ELECT 22uF 20% 50V
C420 1-162-294-31 CERAMIC 0.001uF 10% 50V
C421 1-126-967-11 ELECT 47uF 20% 50V
C422 1-126-967-11 ELECT 47uF 20% 50V
C431 1-126-964-11 ELECT 10uF 20% 50V
C432 1-162-290-31 CERAMIC 470PF 10% 50V
C433 1-162-282-31 CERAMIC 100PF 10% 50V
C434 1-126-947-11 ELECT 47uF 20% 10V
C435 1-136-165-00 FILM 0.1uF 5% 50V
C436 1-136-165-00 FILM 0.1uF 5% 50V
C451 1-126-964-11 ELECT 10uF 20% 50V
C452 1-162-290-31 CERAMIC 470PF 10% 50V
C453 1-162-282-31 CERAMIC 100PF 10% 50V
C454 1-126-947-11 ELECT 47uF 20% 10V
C455 1-136-165-00 FILM 0.1uF 5% 50V
C456 1-136-165-00 FILM 0.1uF 5% 50V
C457 1-126-965-11 ELECT 22uF 20% 50V
C458 1-126-965-11 ELECT 22uF 20% 50V
C470 1-162-294-31 CERAMIC 0.001uF 10% 50V
C471 1-126-967-11 ELECT 47uF 20% 50V
C481 1-126-964-11 ELECT 10uF 20% 50V
C482 1-162-290-31 CERAMIC 470PF 10% 50V
C483 1-162-282-31 CERAMIC 100PF 10% 50V
C484 1-126-947-11 ELECT 47uF 20% 10V
C485 1-136-165-00 FILM 0.1uF 5% 50V
C486 1-136-165-00 FILM 0.1uF 5% 50V
C491 1-164-159-11 CERAMIC 0.1uF 50V
C492 1-164-159-11 CERAMIC 0.1uF 50V
C493 1-128-550-11 ELECT 2200uF 20% 50V
(SP, AUS)
C493 1-137-839-11 ELECT 2200uF 20% 50V
(E2, E51, MX, AR)
C494 1-128-550-11 ELECT 2200uF 20% 50V
(SP, AUS)
C494 1-137-839-11 ELECT 2200uF 20% 50V
(E2, E51, MX, AR)
< CONNECTOR >
CN402 1-774-743-21 CONNECTOR, BOARD TO BOARD 18P
< DIODE >
D401 8-719-911-19 DIODE 1SS133T-72
D402 8-719-911-19 DIODE 1SS133T-72
D421 8-719-911-19 DIODE 1SS133T-72
D431 8-719-911-19 DIODE 1SS133T-72
D432 8-719-911-19 DIODE 1SS133T-72
D451 8-719-911-19 DIODE 1SS133T-72
D452 8-719-911-19 DIODE 1SS133T-72
D481 8-719-911-19 DIODE 1SS133T-72
D482 8-719-911-19 DIODE 1SS133T-72
D491 6-500-249-01 DIODE D15XB20
< IC >
IC401 8-749-016-93 IC STK402-070S
IC431 8-749-016-93 IC STK402-070S
< TRANSISTOR >
Q401 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q419 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q420 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q421 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q422 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q423 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q431 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q451 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q471 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q472 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
DSP FRONT REAR AMP
