Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
43
HCD-FL3
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
Q481 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R401 1-249-417-11 CARBON 1K 5% 1/4W
R402 1-249-437-11 CARBON 47K 5% 1/4W
R403 1-249-413-11 CARBON 470 5% 1/4W
R404 1-249-437-11 CARBON 47K 5% 1/4W
0R405 1-208-602-11 METAL 0.22 2W F
0R406 1-208-602-11 METAL 0.22 2W F
R407 1-249-417-11 CARBON 1K 5% 1/4W
R408 1-249-431-11 CARBON 15K 5% 1/4W
R410 1-249-393-11 CARBON 10 5% 1/4W
0R411 1-212-881-11 FUSIBLE 100 5% 1/4W F
0R412 1-212-881-11 FUSIBLE 100 5% 1/4W F
R416 1-249-441-11 CARBON 100K 5% 1/4W
R417 1-249-441-11 CARBON 100K 5% 1/4W
R418 1-249-440-11 CARBON 82K 5% 1/4W
R419 1-249-429-11 CARBON 10K 5% 1/4W
0R420 1-202-972-61 FUSIBLE 1 5% 1/4W F
R421 1-249-421-11 CARBON 2.2K 5% 1/4W
R422 1-249-433-11 CARBON 22K 5% 1/4W
R423 1-249-439-11 CARBON 68K 5% 1/4W
R424 1-249-426-11 CARBON 5.6K 5% 1/4W
R425 1-249-421-11 CARBON 2.2K 5% 1/4W
R426 1-249-421-11 CARBON 2.2K 5% 1/4W
R427 1-249-435-11 CARBON 33K 5% 1/4W
R428 1-249-431-11 CARBON 15K 5% 1/4W
R431 1-249-417-11 CARBON 1K 5% 1/4W
R432 1-249-437-11 CARBON 47K 5% 1/4W
R433 1-249-415-11 CARBON 680 5% 1/4W
R434 1-249-437-11 CARBON 47K 5% 1/4W
0R435 1-208-602-11 METAL 0.22 2W F
0R436 1-208-602-11 METAL 0.22 2W F
R437 1-249-417-11 CARBON 1K 5% 1/4W
R438 1-249-433-11 CARBON 22K 5% 1/4W
R440 1-249-393-11 CARBON 10 5% 1/4W
R451 1-249-417-11 CARBON 1K 5% 1/4W
R452 1-249-437-11 CARBON 47K 5% 1/4W
R453 1-249-413-11 CARBON 470 5% 1/4W
R454 1-249-437-11 CARBON 47K 5% 1/4W
0R455 1-208-602-11 METAL 0.22 2W F
0R456 1-208-602-11 METAL 0.22 2W F
R457 1-249-417-11 CARBON 1K 5% 1/4W
R458 1-249-431-11 CARBON 15K 5% 1/4W
R460 1-249-393-11 CARBON 10 5% 1/4W
0R461 1-212-881-11 FUSIBLE 100 5% 1/4W F
0R462 1-212-881-11 FUSIBLE 100 5% 1/4W F
R469 1-249-429-11 CARBON 10K 5% 1/4W
0R470 1-202-972-61 FUSIBLE 1 5% 1/4W F
R471 1-249-421-11 CARBON 2.2K 5% 1/4W
R472 1-249-433-11 CARBON 22K 5% 1/4W
R473 1-249-439-11 CARBON 68K 5% 1/4W
R474 1-249-426-11 CARBON 5.6K 5% 1/4W
R475 1-249-421-11 CARBON 2.2K 5% 1/4W
R476 1-249-421-11 CARBON 2.2K 5% 1/4W
R481 1-249-417-11 CARBON 1K 5% 1/4W
R482 1-249-437-11 CARBON 47K 5% 1/4W
R483 1-249-415-11 CARBON 680 5% 1/4W
R484 1-249-437-11 CARBON 47K 5% 1/4W
0R485 1-208-602-11 METAL 0.22 2W F
0R486 1-208-602-11 METAL 0.22 2W F
R487 1-249-417-11 CARBON 1K 5% 1/4W
R488 1-249-433-11 CARBON 22K 5% 1/4W
R490 1-249-393-11 CARBON 10 5% 1/4W
R491 1-249-441-11 CARBON 100K 5% 1/4W
(E2, E51, MX, AR)
R492 1-249-441-11 CARBON 100K 5% 1/4W
(E2, E51, MX, AR)
< THERMISTOR >
TH401 1-807-796-11 THERMISTOR
**************************************************************
A-4728-396-A GC BOARD, COMPLETE
*******************
4-238-986-01 HOLDER (FL)
< CAPACITOR >
C201 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C202 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C203 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C204 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C205 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C206 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C207 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C208 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C209 1-126-964-11 ELECT 10uF 20% 50V
C210 1-126-964-11 ELECT 10uF 20% 50V
C211 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C212 1-126-963-11 ELECT 4.7uF 20% 50V
C213 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C218 1-126-964-11 ELECT 10uF 20% 50V
C219 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C221 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C223 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C241 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C243 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C248 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C250 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C251 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C262 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C277 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C281 1-126-916-11 ELECT 1000uF 20% 6.3V
C282 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C285 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C286 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C287 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C288 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C289 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C290 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C291 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C292 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C293 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C294 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
FRONT REAR AMP GC
