Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
51
HCD-FL3
R857 1-216-833-11 RES-CHIP 10K 5% 1/10W
R858 1-216-833-11 RES-CHIP 10K 5% 1/10W
R859 1-216-809-11 RES-CHIP 100 5% 1/10W
R860 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R861 1-216-841-11 RES-CHIP 47K 5% 1/10W
R862 1-216-837-11 RES-CHIP 22K 5% 1/10W
R863 1-216-837-11 RES-CHIP 22K 5% 1/10W
R864 1-216-849-11 RES-CHIP 220K 5% 1/10W
R865 1-216-841-11 RES-CHIP 47K 5% 1/10W
R866 1-216-843-11 RES-CHIP 68K 5% 1/10W
R867 1-216-843-11 RES-CHIP 68K 5% 1/10W
R868 1-216-843-11 RES-CHIP 68K 5% 1/10W
R869 1-216-841-11 RES-CHIP 47K 5% 1/10W
R870 1-216-843-11 RES-CHIP 68K 5% 1/10W
0R874 1-215-863-11 METAL OXIDE 100 5% 1W F
0R875 1-215-863-11 METAL OXIDE 100 5% 1W F
0R876 1-215-863-11 METAL OXIDE 100 5% 1W F
0R877 1-215-863-11 METAL OXIDE 100 5% 1W F
0R878 1-215-863-11 METAL OXIDE 100 5% 1W F
0R879 1-215-863-11 METAL OXIDE 100 5% 1W F
0R880 1-215-863-11 METAL OXIDE 100 5% 1W F
0R885 1-215-861-00 METAL OXIDE 47 5% 1W F
0R886 1-215-861-00 METAL OXIDE 47 5% 1W F
< VARIABLE RESISTOR >
RV2 1-241-768-11 RES, ADJ, CARBON 220K
RV52 1-241-768-11 RES, ADJ, CARBON 220K
RV53 1-238-019-11 RES, ADJ, CARBON 47K
< RELAY >
RY801 1-515-921-11 RELAY
RY802 1-515-921-11 RELAY
RY803 1-515-921-11 RELAY
RY804 1-515-833-11 RELAY
RY805 1-515-833-11 RELAY
RY806 1-515-833-11 RELAY
RY807 1-515-921-11 RELAY
< TRANSFORMER >
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
< TERMINAL >
TM801 1-694-656-21 TERMINAL BOARD (6CH SPEAKER)
(SPEAKER IMPEDANCE USE 8–16W,
EXCEPT CENTER 16W)
**************************************************************
A-4676-864-A SUB TRANS BOARD, COMPLETE (AUS)
A-4676-874-A SUB TRANS BOARD, COMPLETE (MX)
A-4728-434-A SUB TRANS BOARD, COMPLETE (E2, E51, SP)
A-4730-238-A SUB TRANS BOARD, COMPLETE (AR)
**************************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C901 1-104-665-11 ELECT 100uF 20% 10V
C902 1-126-767-11 ELECT 1000uF 20% 16V
C903 1-164-159-11 CERAMIC 0.1uF 50V
C905 1-126-964-11 ELECT 10uF 20% 50V
C906 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR (3.96MM PITCH) 2P
CN902 1-568-106-11 PIN, CONNECTOR (3.96MM PITCH) 4P
(E2, E51, SP)
* CN902 1-564-321-21 PIN, CONNECTOR (3.96MM PITCH) 2P
(AUS, AR, MX)
CN903 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
< DIODE >
D901 8-719-083-89 DIODE 11ES2N-TB5
D902 8-719-083-89 DIODE 11ES2N-TB5
D903 8-719-083-89 DIODE 11ES2N-TB5
D904 8-719-083-89 DIODE 11ES2N-TB5
D905 8-719-911-19 DIODE 1SS133T-72
D906 8-719-911-19 DIODE 1SS133T-72
< IC >
IC901 8-759-647-10 IC uPC2933HF
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R901 1-249-429-11 CARBON 10K 5% 1/4W
R902 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0RY901 1-755-467-21 RELAY
< SWITCH >
0S901 1-786-055-21 SELECTOR, VOLTAGE (E2, E51, SP)
< TRANSFORMER >
0T901 1-437-677-11 TRANSFORMER, POWER
**************************************************************
1-684-198-11 TC DOOR BOARD
**************
< CONNECTOR >
CN319 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
< DIODE >
D309 8-719-988-61 DIODE 1SS355TE-17
D310 8-719-988-61 DIODE 1SS355TE-17
< SHORT >
JR214 1-216-864-11 SHORT CHIP 0
**************************************************************
SP RELAY SUB TRANS TC DOOR
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
