Sony HCD-FL3 - Page 168

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
52
HCD-FL3
1-684-199-11 TC DOOR SW BOARD
****************
< SWITCH >
S325 1-771-264-11 SWITCH, PUSH (DETECTION) (1 KEY)
(CASSETTE LID OPEN/CLOSE DETECT)
**************************************************************
1-684-200-11 TC SW (A) BOARD
****************
< RESISTOR >
R338 1-216-825-11 RES-CHIP 2.2K 5% 1/10W
< SWITCH >
S326 1-771-410-21 SWITCH, TACTILE (A Z)
**************************************************************
A-4676-862-A TRANS BOARD, COMPLETE (AUS)
A-4676-872-A TRANS BOARD, COMPLETE (MX)
A-4728-426-A TRANS BOARD, COMPLETE (E2, E51, SP)
A-4730-236-A TRANS BOARD, COMPLETE (AR)
***********************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C913 1-128-576-11 ELECT 100uF 20% 63V
C914 1-126-960-11 ELECT 1uF 20% 50V
C915 1-126-968-11 ELECT 100uF 20% 50V
< CONNECTOR >
* CN914 1-564-522-11 PLUG, CONNECTOR 7P
* CN915 1-564-521-11 PLUG, CONNECTOR 6P
* CN916 1-564-523-11 PLUG, CONNECTOR 8P
< DIODE >
D911 8-719-083-89 DIODE 11ES2N-TB5
D912 8-719-983-96 DIODE MTZJ-T-72-39A
D913 8-719-160-29 DIODE RD6.2F-T7B2
D914 8-719-109-68 DIODE MTZJ-T-72-3.6A
< TRANSISTOR >
Q971 8-729-048-52 TRANSISTOR 2SA1932 (TP)
< RESISTOR >
0R913 1-219-124-91 FUSIBLE 0.68 5% 1/4W F
R914 1-249-417-11 CARBON 1K 5% 1/4W
R915 1-249-429-11 CARBON 10K 5% 1/4W
R916 1-247-807-31 CARBON 100 5% 1/4W
R917 1-247-807-31 CARBON 100 5% 1/4W
TC DOOR SW TC SW (A) TRANS
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
