HCD-GT3D
32
SECTION 6
DIAGRAMS
• Circuit Boards Location
MS-476 board
BUTTON board
SPK_HLED board
BLUETOOTH MODULE
LCD board
DAMP board
MIC board
OPTICAL board
MOTHERBOARD board
SMPS board
SPLITTER board
RC-S730 (WW)
