Sony HCD-GT3D - SECTION 8 ELECTRICAL PARTS LIST; BUTTON BOARD

80
HCD-GT3D
SECTION 8
ELECTRICAL PARTS LIST
BUTTON BOARD
*************
< CAPACITOR >
C3107 1-118-695-91 CERAMIC CHIP 0.01uF 5% 50V
C3111 1-118-695-91 CERAMIC CHIP 0.01uF 5% 50V
C3113 1-115-872-11 ELECT 2.2uF 20% 50V
C3117 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
< CONNECTOR >
CN3100 1-779-279-11 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
< DIODE >
D3100 6-504-215-01 DI HL-364V620MZ-T
D3105 6-504-213-01 DI HL-364B460MZ-T
< ROTARY ENCODER >
EN3100 1-493-009-11 ENCODER, ROTARY (MULTI CONTROL)
EN3101 1-493-007-11 ENCODER, ROTARY (VOLUME/DJ CONTROL)
< JUMPER RESISTOR >
JR3100 1-216-296-11 SHORT CHIP 0
JR3101 1-216-296-11 SHORT CHIP 0
JR3102 1-216-296-11 SHORT CHIP 0
JR3103 1-216-296-11 SHORT CHIP 0
JR3104 1-216-296-11 SHORT CHIP 0
< RESISTOR >
R3123 1-216-864-11 SHORT CHIP 0
R3124 1-216-864-11 SHORT CHIP 0
R3125 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3129 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3130 1-216-819-11 METAL CHIP 680 5% 1/10W
R3131 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3132 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3133 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3134 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R3135 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R3136 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3137 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R3138 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3139 1-216-837-11 METAL CHIP 22K 5% 1/10W
R3140 1-216-835-11 METAL CHIP 15K 5% 1/10W
R3141 1-216-835-11 METAL CHIP 15K 5% 1/10W
R3142 1-216-819-11 METAL CHIP 680 5% 1/10W
R3143 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3144 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3145 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3146 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R3147 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R3148 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3149 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R3150 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VARISTOR >
RV3100 1-227-918-11 RES, VAR, CARBON 50K (MIC LEVEL)
< SWITCH >
S3100 1-762-875-21 SWITCH, TACTILE (:/1)
S3101 1-762-875-21 SWITCH, TACTILE (x)
S3102 1-762-875-21 SWITCH, TACTILE (N)
S3103 1-762-875-21 SWITCH, TACTILE (-PAIRING BLUETOOTH)
S3104 1-762-875-21 SWITCH, TACTILE (MEGA BASS)
S3105 1-762-875-21 SWITCH, TACTILE (LIGHT MODE)
S3106 1-762-875-21 SWITCH, TACTILE (ENTER)
S3107 1-762-875-21 SWITCH, TACTILE (FUNCTION)
S3108 1-762-875-21 SWITCH, TACTILE (SOUND FIELD)
S3109 1-762-875-21 SWITCH, TACTILE (DJ EFFECT FLANGER)
S3110 1-762-875-21 SWITCH, TACTILE (DJ EFFECT ISOLATOR)
S3111 1-762-875-21 SWITCH, TACTILE (DJ EFFECT DJ OFF)
S3112 1-762-875-21 SWITCH, TACTILE (DJ EFFECT SAMPLER)
S3113 1-762-875-21 SWITCH, TACTILE (PARTY CHAIN)
S3114 1-762-875-21 SWITCH, TACTILE (Z)
S3115 1-762-875-21 SWITCH, TACTILE (PARTY LIGHT)
S3116 1-762-875-21 SWITCH, TACTILE (FOOTBALL)
S3117 1-762-875-21 SWITCH, TACTILE (S3 TUNING - .)
S3118 1-762-875-21 SWITCH, TACTILE (S4 TUNING + >)
S3119 1-762-875-21 SWITCH, TACTILE (S1  -)
S3120 1-762-875-21 SWITCH, TACTILE (S2  +)
S3121 1-762-875-21 SWITCH, TACTILE (VOCAL FADER)
S3122 1-762-875-21 SWITCH, TACTILE (MIC ECHO)
S3123 1-762-875-21 SWITCH, TACTILE (REC TO USB)
*************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• CAPACITORS
uF: μF
• COILS
uH: μH
• Abbreviation
AR : Argentina model
AUS : Australian model
E4 : African model
EA : Saudi Arabia model
LA9 : Latin-American model
MY : Malaysia model
RU : Russian model
TH : Thai model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
The components identifi ed by mark 9
contain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
BUTTON
Ver. 1.2
