Sony HCD-GT3D Service Manual

HCD-GT3D
9
Note: Disassemble the unit in the order as shown below.
2-1. DISASSEMBLY FLOW
SECTION 2
DISASSEMBLY
2-3. TOP PANEL SECTION
(Page 11)
2-4. OPTICAL BOARD
(Page 12)
2-5. LOADING PANEL ASSY
(Page 12)
2-11. SMPS BOARD
(Page 17)
2-12. CHASSIS
(Page 17)
2-10. SUB CHASSIS SECTION
(Page 16)
2-14. LOUDSPEAKER (20CM)-087-11
(Page 19)
2-13. FRONT PANEL SECTION
(Page 18)
2-8. DAMP BOARD
(Page 14)
2-7. BACK PANEL
(Page 13)
2-6. CDM SECTION
(Page 13)
2-15. SERVICE, OPTICAL DEVICE(7G), WIRE (FLAT TYPE)
(Page 20)
2-2. SIDE (L) PANEL, SIDE (R) PANEL
(Page 10)
2-9. MOTHERBOARD BOARD,
SPLITTER BOARD
(Page 15)
SET

Sony HCD-GT3D Specifications

General

Brand	Sony
Model	HCD-GT3D
Category	Receiver
Language	English
