Sony HCD-GT3D - SECTION 7 EXPLODED VIEWS; 7-7. CDM SECTION

78
HCD-GT3D
7-7. CDM SECTION
301 2-345-115-01 SCREW (S), FLOAT
302 4-535-577-01 STEP SCREW M2.6
303 4-533-382-01 INSULATOR
304 4-533-939-01 SPRING, INSULATOR (F)
305 4-533-940-01 SPRING, INSULATOR (R)
#1 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
Ref. No. Part No. Description Remark
CD mechanism section
(CDM90-DVBU204//M)
not supplied
not supplied
not supplied
304
304
303
305
305
302
301
301
303
302
303
302
303
302
#1
Ver. 1.2
