Sony HCD-GT3D - SECTION 6 DIAGRAMS; 6-29. PRINTED WIRING BOARD - SPLITTER Board -

HCD-GT3D
HCD-GT3D
5858
1
A
B
C
D
E
F
2 3 4 5 6 78
2
1
12
13
CN3401
2
1
10
11
CN3402
R001
R002
R003
1
2
25
24
CN3400
R006
R007
R004
R005
R008
JL3400 JL3401
1-894-358-
12
(12)
1-894-358-
12
(12)
SPLITTER BOARD
(COMPONENT SIDE)
SPLITTER BOARD
(CONDUCTOR SIDE)
>005P
MOTHERBOARD
BOARD
CN118
(Page 39)
>010P
LCD BOARD
CN3000
(Page 55)
>009P
BUTTON BOARD
CN3100
(Page 53)
(CHASSIS)
(CHASSIS)
1
A
B
C
D
E
2 3 4 5 6 78
CN3400
25P
1
OSC
2
JOG_NEG
3
JOG_POS
4
LCD_BCK_LED
5
NC
6
NC
7
RED_LED
8
BLUE_LED
9
NC
10
VOL
11
POWER_KEY
12
SIRCS
13
E+3.3V
14
DGND
15
AD_KEY1
16
AD_KEY0
17
LCD_CSB
18
LCD_INHB
19
LCD_SDA
20
LCD_SCL
21
LED_GND
22
LED_GND
23
LED+5.2V
24
LED+5.2V
25
NC
0
R001
CN3401
13P
13 LED+5.2V
12 LED+5.2V
11 LED_GND
10 LED_GND
9LED_SCL
8LCD_SDA
7 LCD_INHB
6LCD_CSB
5 SIRCS
4 E+3.3V
3 LCD_BCK_LED
2OSC
1DGND
0
R002
JL3400
CN3402
11P
11 LED+5.2V
10 LED+5.2V
9 AD-KEY0
8 AD-KEY1
7DGND
6 POWER-KEY
5VOL
4 BLUE_LED
3 RED_LED
2 JOG_POS
1 JOG_NEG
JL3401
0R008
0R004
0R005
0
R006
0
R003
0
R007
SPLITTER BOARD
>039S
MOTHERBOARD
BOARD
(10/10)
CN118
(Page 49)
>046S
LCD
BOARD
CN3000
(Page 55)
>047S
BUTTON
BOARD
CN3100
(Page 54)
6-29. PRINTED WIRING BOARD - SPLITTER Board -
• See page 32 for Circuit Boards Location. • : Uses unleaded solder.
6-30. SCHEMATIC DIAGRAM - SPLITTER Board -
Ver. 1.1
