Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GT3D
81
A-2061-348-A DAMP BOARD, COMPLETE
*********************
< CAPACITOR >
C1001 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1002 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1003 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C1004 1-128-991-21 ELECT CHIP 10uF 20% 50V
* C1005 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
C1007 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1008 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C1011 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C1012 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1015 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1020 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
* C1021 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
C1022 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1026 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1029 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1036 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1037 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1038 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1039 1-164-934-11 CERAMIC CHIP 330PF 10% 50V
C1040 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C1043 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C1044 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C1045 1-118-369-11 CERAMIC CHIP 0.022uF 10% 50V
C1046 1-118-369-11 CERAMIC CHIP 0.022uF 10% 50V
C1047 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C1048 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C1049 1-118-369-11 CERAMIC CHIP 0.022uF 10% 50V
C1050 1-118-369-11 CERAMIC CHIP 0.022uF 10% 50V
C1051 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C1052 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C1053 1-118-369-11 CERAMIC CHIP 0.022uF 10% 50V
C1054 1-118-369-11 CERAMIC CHIP 0.022uF 10% 50V
C1055 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C1056 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C1057 1-118-369-11 CERAMIC CHIP 0.022uF 10% 50V
C1058 1-118-369-11 CERAMIC CHIP 0.022uF 10% 50V
C1059 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
* C1060 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
* C1061 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
C1062 1-116-708-11 CERAMIC CHIP 47uF 20% 6.3V
C1063 1-116-708-11 CERAMIC CHIP 47uF 20% 6.3V
C1067 1-114-831-91 CERAMIC CHIP 1uF 10% 100V
C1068 1-114-831-91 CERAMIC CHIP 1uF 10% 100V
C1074 1-116-911-21 CERAMIC CHIP 1uF 10% 250V
C1075 1-116-911-21 CERAMIC CHIP 1uF 10% 250V
C1076 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
C1077 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C1078 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C1079 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
C1080 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
C1081 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C1082 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
C1083 1-128-403-11 ELECT CHIP 47uF 20% 35V
C1089 1-128-991-21 ELECT CHIP 10uF 20% 50V
* C1090 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
C1091 1-128-991-21 ELECT CHIP 10uF 20% 50V
C1092 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
* C1095 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
C1104 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C1105 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C1106 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C1107 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C1108 1-126-193-11 ELECT CHIP 1uF 20% 50V
C1117 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1118 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1119 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1120 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1121 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
C1122 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
C1123 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C1124 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C1125 1-116-708-11 CERAMIC CHIP 47uF 20% 6.3V
C1126 1-112-247-31 ELECT 220uF 20% 35V
C1127 1-112-247-31 ELECT 220uF 20% 35V
C1128 1-112-247-31 ELECT 220uF 20% 35V
C1129 1-112-247-31 ELECT 220uF 20% 35V
* C1131 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
C1132 1-118-371-11 CERAMIC CHIP 0.015uF 10% 50V
* C1133 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
C1134 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1136 1-137-765-21 ELECT CHIP 47uF 20% 16V
C1137 1-165-492-21 ELECT CHIP 100uF 20% 10V
C1138 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
C1139 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
C1140 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
C1141 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
C1142 1-118-933-11 ELECT (BLOCK) 3300uF 20% 71V
C1143 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C1144 1-165-492-21 ELECT CHIP 100uF 20% 10V
C1147 1-112-514-91 CERAMIC CHIP 1500PF 5% 50V
C1148 1-118-381-11 CERAMIC CHIP 0.0022uF 10% 50V
* C1149 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C1150 1-112-514-91 CERAMIC CHIP 1500PF 5% 50V
C1151 1-118-381-11 CERAMIC CHIP 0.0022uF 10% 50V
C1155 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C1156 1-114-588-91 CERAMIC CHIP 0.0027uF 5% 50V
C1167 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
C1168 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
C1169 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
< CONNECTOR >
CN1001 1-820-117-51 CONNECTOR, FFC/FPC 19P
CN1004 1-770-469-21 PIN, CONNECTOR (PC BOARD) 2P
CN1005 1-691-770-11 PLUG (MICRO CONNECTOR) 8P
CN1007 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
D1001 6-500-400-01 DIODE BAV99-215
D1002 6-500-400-01 DIODE BAV99-215
D1005 6-500-400-01 DIODE BAV99-215
D1006 6-500-400-01 DIODE BAV99-215
D1007 8-719-073-35 DIODE RB551V-30TE-17
D1008 6-500-400-01 DIODE BAV99-215
D1013 6-502-961-01 DI DA2J10100L
D1014 6-502-970-01 DI DZ2J068M0L
D1016 6-503-987-01 DI RF05VAM2STR
D1017 8-719-073-35 DIODE RB551V-30TE-17
DAMP
Note 1: When the complete DAMP board is replaced, re-
fer to “NOTE OF REPLACING THE IC1001 ON
THE DAMP BOARD AND THE COMPLETE DAMP
BOARD” on servicing notes (page 5).
Note 2:
When the C1126, C1127, C1128, C1129 and C1142 on the
DAMP board are replaced, spread the bond referring to “BOND
FIXATION OF ELECTRIC PARTS” on servicing notes (page 6).
Ver. 1.1
