Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GT3D
82
< IC >
IC1001 6-716-817-01 IC TAS5630BPHDR
IC1003 6-716-462-01 IC BD00GA3WEFJ-E2
IC1004 8-759-274-71 IC NJM4565M (TE2)
IC1005 8-759-274-71 IC NJM4565M (TE2)
< JUMPER >
JC1019 1-216-295-91 SHORT CHIP 0
JC1020 1-216-295-91 SHORT CHIP 0
< COIL >
L1006 1-482-158-11 INDUCTOR 10uH
L1007 1-482-158-11 INDUCTOR 10uH
L1009 1-400-793-21 INDUCTOR 47uH
L1010 1-482-160-21 INDUCTOR 20uH
< TRANSISTOR >
Q1003 8-729-216-22 TRANSISTOR 2SA1162-G
Q1004 8-729-216-22 TRANSISTOR 2SA1162-G
Q1006 6-552-892-01 TR LSCR523UBFS8TL
Q1010 6-552-746-01 TR DSA700300L
Q1011 6-552-892-01 TR LSCR523UBFS8TL
Q1014 8-729-216-22 TRANSISTOR 2SA1162-G
Q1015 8-729-216-22 TRANSISTOR 2SA1162-G
Q1016 8-729-216-22 TRANSISTOR 2SA1162-G
Q1017 8-729-216-22 TRANSISTOR 2SA1162-G
Q1018 6-553-509-01 TR KTA1542T-RTK/P
Q1019 6-553-083-01 TR PBSS4160T
Q1021 6-552-892-01 TR LSCR523UBFS8TL
Q1022 6-552-892-01 TR LSCR523UBFS8TL
Q1023 6-552-892-01 TR LSCR523UBFS8TL
< RESISTOR >
R1001 1-208-715-11 METAL CHIP 22K 0.50% 1/16W
R1002 1-218-941-81 METAL CHIP 100 5% 1/16W
R1003 1-218-941-81 METAL CHIP 100 5% 1/16W
R1004 1-218-941-81 METAL CHIP 100 5% 1/16W
R1005 1-218-941-81 METAL CHIP 100 5% 1/16W
R1008 1-218-941-81 METAL CHIP 100 5% 1/16W
R1009 1-208-911-11 METAL CHIP 10K 0.50% 1/16W
R1011 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1012 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1017 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1018 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1020 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1021 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1022 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1023 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1024 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1025 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1026 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1027 1-216-791-11 METAL CHIP 3.3 5% 1/10W
* R1028 1-250-684-11 METAL CHIP 680K 1% 1/10W
* R1029 1-250-684-11 METAL CHIP 680K 1% 1/10W
* R1030 1-250-684-11 METAL CHIP 680K 1% 1/10W
R1031 1-216-849-11 METAL CHIP 220K 5% 1/10W
R1032 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1033 1-216-849-11 METAL CHIP 220K 5% 1/10W
R1035 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1036 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1037 1-216-819-11 METAL CHIP 680 5% 1/10W
R1052 1-250-535-11 METAL CHIP 47K 1% 1/16W
* R1053 1-250-507-11 METAL CHIP 3.3K 1% 1/16W
R1062 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1063 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1064 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1065 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R1066 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1067 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R1068 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R1069 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1070 1-216-838-11 METAL CHIP 27K 5% 1/10W
R1072 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1076 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1077 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1078 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1079 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1080 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1081 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1082 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1083 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1084 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1085 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1087 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1088 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1091 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1092 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1106 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1111 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1112 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1126 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1127 1-216-834-11 METAL CHIP 12K 5% 1/10W
R1128 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1129 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1130 1-216-805-11 METAL CHIP 47 5% 1/10W
R1131 1-216-805-11 METAL CHIP 47 5% 1/10W
R1132 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1133 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1134 1-216-295-91 SHORT CHIP 0
R1135 1-216-295-91 SHORT CHIP 0
R1136 1-216-295-91 SHORT CHIP 0
R1137 1-216-295-91 SHORT CHIP 0
R1138 1-216-836-11 METAL CHIP 18K 5% 1/10W
R1139 1-216-864-11 SHORT CHIP 0
R1141 1-208-911-11 METAL CHIP 10K 0.50% 1/16W
R1145 1-218-855-11 METAL CHIP 2.2K 0.50% 1/10W
R1147 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1148 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R1149 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1150 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1151 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1152 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R1153 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R1154 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R1155 1-250-634-11 METAL CHIP 5.6K 1% 1/10W
R1156 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1157 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1158 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1159 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1160 1-216-864-11 SHORT CHIP 0
DAMP
Note : When the L1010 on the DAMP board is replaced,
spread the bond referring to “BOND FIXATION OF
ELECTRIC PARTS” on servicing notes (page 6).
