HCD-GT3D
71
Pin No. Pin Name I/O Description
61 DQM0 O Data mask signal output to the SD-RAM
62 to 69 RD15 to RD8 I/O Two-way data bus with the SD-RAM
70 DQM1 O Data mask signal output to the SD-RAM
71 DVDD33 - Power supply terminal (+3.3V) (for digital system)
72 RCLK O Clock signal output to the SD-RAM
73 to 79 RA11, RA9 to RA4 O Address signal output to the SD-RAM
80 RWE# O Write enable signal output to the SD-RAM
81 DVSS12 - Ground terminal (for digital system)
82 CAS# O Column address strobe signal output to the SD-RAM
83 RAS# O Row address strobe signal output to the SD-RAM
84 DVDD33 - Power supply terminal (+3.3V) (for digital system)
85 BA0 O Bank address signal output to the SD-RAM
86 BA1 O Bank address signal output to the SD-RAM
87 DVDD12 - Power supply terminal (+1.2V) (for digital system)
88 to 92 RA10, RA0 to RA3 O Address signal output to the SD-RAM
93 SPDIF - Not used
94 XMAMUTE - Not used
95 NC - Not used
96 DACVDDC - Power supply terminal (+3.3V) (for D/A converter)
97 VREF I Band gap reference voltage terminal
98 FS I Full scale adjustment terminal
99 DACVSSC - Ground terminal (for D/A converter)
100 CVBS O Composite video signal output terminal
101 DACVDDB - Power supply terminal (+3.3V) (for D/A converter)
102 SY/Y/G - Not used
103 SC/CB/B - Not used
104 CR/R - Not used
105 AADVSS - Ground terminal (for D/A converter)
106 ADIN I Audio data input from the A/D converter
107 NC - Not used
108 NC - Not used
109 AADVDD - Power supply terminal (+3.3V) (for D/A converter)
110 ADACVSS2 - Ground terminal (for D/A converter)
111 ADACVSS1 - Ground terminal (for D/A converter)
112 ACLK O Master clock signal output
113 ABCK O Bit clock signal output
114 NC - Not used
115 AVCM I Audio D/A converter reference voltage terminal
116 NC - Not used
117 ALRCK O L/R sampling clock signal output
118 ASDATA0 O Audio data output
119 ADACVDD1 - Power supply terminal (+3.3V) (for D/A converter)
120 ADACVDD2 - Power supply terminal (+3.3V) (for D/A converter)
121 AVDD12_1 - Power supply terminal (+1.2V) (for analog system)
122 AGND12 - Ground terminal (for analog system)
123 RFIP I AC coupled RF signal input from the optical pick-up block
124 OPDIST I Optical pick-up block type selection
125 IOPMON/OPO I Power monitor terminal
126 SPFG/OP I Spindle motor hall sensor input from the motor driver
127 RF_A I RF main beam A input from the optical pick-up block
128 RF_B I RF main beam B input from the optical pick-up block
