1-3. Installation Space
1-3-1. External Dimensions
Main panel/AUX panel
*
/Menu panel
* A configuration using MKS-X7017/X7018/X7019 independently is called “AUX panel” in this manual.
584.8
Unit: mm
160
146
473
64
863
1522
1376.8 72.672.6
60140
102
9.8
93
84
90
1482
768.6
42446
213
221
