ICP-X7000
1-30 (E)
1-12. Matching Connectors and Cables
Use the following connectors, cables or equivalents when connecting cables to the unit.
Model name Panel indication Connector name Matching connector and cable
Name
MKS-X2700 REMOTE 1 to 6
SERIAL TALLY1, 2
D-sub 9pin, Female D-sub 9-pin, Male
Connector 9-pin, Male
Junction Shell 9-pin
TALLY/GPI OUT 1-18
TALLY/GPI OUT 19-36
TALLY/GPI IN 1-34
D-sub 37pin, Female D-sub 37-pin, Male
Connector 37-pin, Male
Junction Shell 37-pin
S-BUS
REF IN
BNC, 75 Z Belden 1694 coaxial cable
MVS
UTIL
RJ-45 modular jack
*1
CAT5e or equivalent
*2
MKS-X7700 REMOTE1 to 4
SERIAL TALLY1, 2
D-sub 9pin, Female D-sub 9-pin, Male
Connector 9-pin, Male
Junction Shell 9-pin
TALLY/GPI IN 1-34
TALLY/GPI IN 35-68
D-sub 37pin, Female D-sub 37-pin, Male
Connector 37-pin, Male
Junction Shell 37-pin
S-BUS
REF IN
BNC, 75 Z Belden 1694 coaxial cable
MVS
UTIL
RJ-45 modular jack
*1
CAT5e or equivalent
*2
MKS-X7701 TALLY/GPI OUT 1-18
TALLY/GPI OUT 19-36
TALLY/GPI OUT 37-54
D-sub 37pin, Female D-sub 37-pin, Male
Connector 37-pin, Male
Junction Shell 37-pin
MKS-X7702 REMOTE1 to 6 D-sub 9pin, Female D-sub 9-pin, Male
Connector 9-pin, Male
Junction Shell 9-pin
MKS-X7011 LAN
*3
RJ-45 modular jack
*1
CAT5e or equivalent
*2
DEVICE
*4
USB Type A receptacle
ICP-X7000 LAN
*3
RJ-45 modular jack
*1
CAT5e or equivalent
*2
MKS-X7075
*1: Conforms to IEEE 802.3 Ethernet 1000BASE-TX standard.
*2: Shield type is recommended.
*3: Compliance with PoE + (IEEE802.3at)
*4: Compliance with USB2.0
