Sony ICP-X7000

ICP-X7000
1-58 (E)
1-15-2. Example of Connection to XVS Series
*1: PC is only required when performing the “1-17. Maintenance Menu”.
*2: Required when using the Web Application of the XVS series.
Reference video
signal
Reference video
signal
DC IN LAN
DC IN LAN
DC IN LAN
per row
LAN2 LAN1
MVS LAN
MVS
REF IN
LAN
Reference video
signal
MVS
REF IN
To AC adaptor
To AC adaptor
To AC adaptor
Integrated Control Panel
ICP-X7000
System Interface Unit
MKS-X7700
System Interface Unit
MKS-X2700
Menu Panel
MKS-X7011
Multiformat Switcher
Switcher Control Station
PWS-100SC1/PWS-110SC1
XVS Series
PC
*1
PC or tablet
*2
PoE+
Ethernet Switch
To AC adaptor
Extension Adaptor
MKS-X7075
