2-4-5. Connectors and Cables
Use the following connectors (or cables) or equivalents for cable connection.
Panel Indication Applicable Connector (Cable) Sony Part No. Remarks
HDMI HDMI type A
Use the cable that meets any of the following
specifications.
High Speed HDMI Cable, Premium High Speed
HDMI Cable
__
USB Use a cable for super speed USB.
__
LAN1/2 Network cable
STP
*
cable is recommended
_
Commercially
available
*STP: Shielded Twisted Pair
2-4-6. Settings of Onboard Switch
n
Except for S800-8, do not change the default settings of switches on the MB-1204 board when installing
the unit.
Board Ref No. Bit
Name
Function Factory Setting
(■: Knob position)
MB-1204 S800
1-7
8
_
Factory use
ON: When AC power is supplied to the rear
unit, the PWS-110SC1 starts.
OFF: When the On/Standby button on the
front panel is pressed, the PWS-
110SC1 starts.
1
2
O
N
3
4
5
6
7 8
S2201 1-4 CFG Factory use
1
2
O
N
3
4
