Sony ICP-X7000

ICP-X7000
3-1 (E)
3-1. Troubleshooting
3-1-1. MKS-X2700, MKS-X7700
The main power cannot be turned on. (LED indi-
cator does not light green.)
Section 3
Service Overview
3-1-2. MKS-X7011
Nothing is displayed on the menu monitor screen.
YES
NO
NO
YES
Flow 1
The main power of the
MKS-X2700/X7700 cannot
be turned on. (Indicator
does not light green.)
Is the POWER switch of the
MKS-X2700/X7700 turned
ON?
Is the power cord of the
MKS-X2700/X7700
connected correctly?
The power supply unit is
probably defective.
Set it to ON.
Connect it correctly.
Nothing is displayed on the
menu monitor screen.
Is PoE HUB powered on?
(When PoE HUB is used)
Is the left side switches on
the MKS-X7011 lit?
Check the power supply of
AC adapter.
YES
YES
NO
NO
The MKS-X7011 is probably
defective.
NO
YES
Flow 2
Is the supplied AC adapter
connected correctly to
DC IN? (When AC adapter
is used)
LCD of the MKS-X7011 is
probably defective.
Check the using PoE HUB
status.
