Sony ICP-X7000

ICP-X7000
1-33 (E)
TALLY/GPI IN 1-34
TALLY/GPI IN 35-68
D-sub 37pin, Female, +3.3 V TTL input
Pin
No.
Signal Name Function
TALLY/GPI
IN 1-34
TALLY/GPI
IN 35-68
1 GPI IN1 GPI IN35 General-purpose input
2 GPI IN3 GPI IN37
3 GPI IN5 GPI IN39
4 GPI IN7 GPI IN41
5 GPI IN9 GPI IN43
6 GPI IN11 GPI IN45
7 GPI IN13 GPI IN47
8 GPI IN15 GPI IN49
9 GPI IN17 GPI IN51
10 GPI IN19 GPI IN53
11 GPI IN21 GPI IN55
12 GPI IN23 GPI IN57
13 GPI IN25 GPI IN59
14 GPI IN27 GPI IN61
15 GPI IN29 GPI IN63
16 GPI IN31 GPI IN65
17 GPI IN33
*1
GPI IN67
*1
18 GND GND GND
19 GND GND
20 GPI IN2 GPI IN36 General-purpose input
21 GPI IN4 GPI IN38
22 GPI IN6 GPI IN40
23 GPI IN8 GPI IN42
24 GPI IN10 GPI IN44
25 GPI IN12 GPI IN46
26 GPI IN14 GPI IN48
27 GPI IN16 GPI IN50
28 GPI IN18 GPI IN52
29 GPI IN20 GPI IN54
30 GPI IN22 GPI IN56
31 GPI IN24 GPI IN58
32 GPI IN26 GPI IN60
33 GPI IN28 GPI IN62
34 GPI IN30 GPI IN64
35 GPI IN32 GPI IN66
36 GPI IN34
*1
GPI IN68
*1
37 GND GND GND
*1: This pin can be used as a +12 V input pin by setting the switch S1601 on
the CA-90 board to ON.
(Refer to “CA-90 board” in “1-14. Description of On-board Switches and
LEDs”.)
MVS
UTIL
1000BASE-T
RJ-45 (8pin)
Pin No. Signal Name Function
1 TRX1+ Transmitted/Received data (+)
2 TRX1_ Transmitted/Received data (_)
3 TRX2+ Transmitted/Received data (+)
4 TRX3+ Transmitted/Received data (+)
5 TRX3_ Transmitted/Received data (_)
6 TRX2_ Transmitted/Received data (_)
7 TRX4+ Transmitted/Received data (+)
8 TRX4_ Transmitted/Received data (_)
1-13-3. MKS-X7701
TALLY/GPI OUT 1-18, TALLY/GPI OUT 19-36
TALLY/GPI OUT 37-54
D-sub 37pin, Female, relay contacts 30 V 0.1 A
Pin
No.
Signal Name Function
TALLY/
GPI OUT
1-18
TALLY/
GPI OUT
19-36
TALLY/
GPI OUT
37-54
1 OUT_1A OUT_19A OUT_37A General-
purpose
relay
output(A)
*1
2 OUT_2A OUT_20A OUT_38A
3 OUT_3A OUT_21A OUT_39A
4 OUT_4A OUT_22A OUT_40A
5 OUT_5A OUT_23A OUT_41A
6 OUT_6A OUT_24A OUT_42A
7 OUT_7A OUT_25A OUT_43A
8 OUT_8A OUT_26A OUT_44A
9 OUT_9A OUT_27A OUT_45A
10 OUT_10A OUT_28A OUT_46A
11 OUT_11A OUT_29A OUT_47A
12 OUT_12A OUT_30A OUT_48A
13 OUT_13A OUT_31A OUT_49A
14 OUT_14A OUT_32A OUT_50A
1
20
19
37
External View

External View
18
1
20
19
37
External View
