Sony ICP-X7000

ICP-X7000
1-27 (E)
2. Rack mounting procedure
The following describes the rack mounting procedure using
the rack mount kit RMM-10.
n
Tighten screws to the following torque.
Tightening torque
MKS-X2700: 0.8 N.m {8.13 kgf.cm}
MKS-X7700: 120 x 10
_2
N.m {12.2 kgf.cm}
1. Sufficiently loosen the four screws (with stopper) to
detach the four feet.
Screws
(with stopper)
Feet
MKS-X2700
MKS-X7700
Screws
(with stopper)
Feet
Screws
(with stopper)
Feet
Screws
(with stopper)
Feet
2. Attach the rack tools to the side panels of the unit with
the specified six screws.
n
Use B4 x 6 screws.
Rack tool
Rack tool
B4 ) 6
B4 ) 6
MKS-X2700
B4 ) 6
Rack tool
Rack tool
B4 ) 6
MKS-X7700
