KY-724 board (MKS-X7018/MKS-X7019)
<LED>
D100 (C-2): +12 V
+12 V power supply status indication.
Lit when the +12 V power is supplied correctly.
<Switch>
S500 (C-1): RECONF
Pressing this switch initializes KY-724 board.
S301 (C-1): SETTING2
This switch is used for manufacturing at the factory.
Do not change the setting of this switch.
D100
S301
S500
1
2
3
ABCD
KY-724 board (Side A)
