Sony MVS-3000 System - Page 284

284
Menus of Disabled Operations and Settings
Appendix
7321.6 Engineering Setup >Panel >Config
>External Bus Link >Link Bus Adjust
• Selection of items related to M/E-2
• Selection of items related to Key5 to 8
7321.7 Engineering Setup >Panel >Config
>Region Button Assign
M/E-2, DME selection
7321.9 Engineering Setup >Panel >Config
>Transition Module
• KEY5 to KEY8, KEY1/5 to KEY 4/8 selection
• ADD, SHIFT selection
7321.18 Engineering Setup >Panel >Config
>Util Bus/Key Inhibit
• M/E-2 settings
• [Key5] to [Key8] selection
7321.19 Engineering Setup >Panel >Config
>Menu Panel
All menu operations
7321.27 Engineering Setup >Panel >Config
>TB Module DME Ch Inhibit
All menu operations
7322 Engineering Setup >Panel >Xpt
Assign
• Setting of items related to M/E-2, DME
• [Audio Follow] settings
7322.5 Engineering Setup >Panel >Xpt
Assign >Main, V/K Pair Assign
Primary33 to Primary48, DME Monitor Video, DME Monitor Key, M/E2
OUT1 to M/E2 OUT4 selection
7322.6 Engineering Setup >Panel >Xpt
Assign >Src Name/Src Color
Primary 33 to 48, DME Monitor Video, DME Monitor Key, M/E-2 Out1 to
M/E-2 Out4 settings
7322.11 Engineering Setup >Panel >Xpt
Assign >Mixer Xpt Assign
All menu operations
7324 Engineering Setup >Panel >Prefs/
Utility
• Selection of following utility commands:
DME Monitor Video ST, DME Monitor Key ST, DME2 GPI Enbl, DME
Override, DME Graphic
• [Menu Shortcut] settings
7324.2 Engineering Setup >Panel >Prefs/
Utility >Xpt Module Src/Reg Btn
Assign
Selection of following utility commands:
DME Monitor Video ST, DME Monitor Key ST, DME2 GPI Enbl, DME
Override, DME Graphic
7325.1 Engineering Setup >Panel >Device
Interface >GPI Input
• Primary 33 to 48 selection when Action is set to Aux Bus Xpt Override
•[M/E-2] selection
• Selection of the following items when Trigger Type is not set to Level in
[M/E-1] (x=5 to 8): Keyx Cut, Keyx Auto Trans, Keyx SS ? Recall
• Selection of the following items when Trigger Type is not set to Level in
[P/P] (x=5 to 8): DSKx Cut, DSKx Auto Trans, DSKx SS ? Recall
7325.3 Engineering Setup >Panel >Device
Interface >GPI Output
•[M/E-2] selection
• Selection of the following items when Trigger Type is not set to Status
in [M/E-1] (x=5 to 8): Keyx SS ? Recall
• Selection of the following items when Trigger Type is set to Status in
[M/E-1] (x=5 to 8): Keyx SS ? Recall, Keyx On
• Selection of the following items when Trigger Type is not set to Status
in [P/P] (x=5 to 8): DSKx SS ? Recall
• Selection of the following items when Trigger Type is set to Status in
[P/P] (x=5 to 8): DSKx SS ? Recall, DSKx On
7326.11 Engineering Setup >Panel
>Operation >Custom Button >Next
Trans All
Key5 to 8 selection
7326.13 Engineering Setup >Panel
>Operation >Key/AUX/Function
Assign
• M/E-2 settings
• Key5 to 8, EXT DME, DME1 V, K, DME2 V, K, DME5 V, K to DME8 V, K
selection
7331 Engineering Setup >Switcher >Config M/E-2 settings
7331.1 Engineering Setup >Switcher >Config
>M/E Output Assign
M/E-2 settings
7331.2 Engineering Setup >Switcher >Config
>PGM Config
• M/E-2 settings
• [Key5] to [Key8] selection
Menu Disabled operation/setting
Number Path
