293
Macro File Editing Rules
Appendix
Rewind Device? 1 to 12, FrameMemory1Clip to
FrameMemory8Clip
Applicable device
DiskFileLoad Device? 1 to 12 Applicable device
FileName? File Name Name of file being set (max. 23 characters)
Snapshot Region? ME1, PP, User1 to User8,
Router
Applicable region
Register? 1 to 99 Applicable register number
Attribute? Off, Dissolve, AutoTransition,
Dissolve&AutoTransition
Applicable snapshot attributes
Time? Current (a), 0 to 999 Duration of effect dissolve (number of frames)
(a): Mode in which the currently set value is
used
KeySnapshot ME? ME1, PP Control blocks on the applicable bank
Key? Key1 to Key4 Applicable key
Register? 1 to 4 Applicable register number
WipeSnapshot ME? ME1, PP Control blocks on the applicable bank
Register? 1 to 10 Applicable register number
DMEWipeSnapshot ME? ME1, PP Control blocks on the applicable bank
Register? 1 to 10 Applicable register number
TimelineRecall Region? ME1, PP, User1 to User8,
PBus, Device1 to Device12,
GPI
Applicable region
Register? 1 to 399 Applicable register number
TimelineRun Region? ME1, PP, User1 to User8,
PBus, Device1 to Device12,
GPI, Current (a)
Applicable region
(a): Mode in which operation takes place in the
region currently specified in the Flexi Pad
TimelineRewind Region? ME1, PP, User1 to User8,
PBus, Device1 to Device12,
GPI, Current (a)
Applicable region
(a): Mode in which operation takes place in the
region currently specified in the Flexi Pad
TimelineFF Region? ME1, PP, User1 to User8,
PBus, Device1 to Device12,
GPI, Current (a)
Applicable region
(a): Mode in which operation takes place in the
region currently specified in the Flexi Pad
Shotbox Register? 1 to 99 Applicable register number
Pause Time? 0 to 999 Time for which macro is paused (number of
frames)
StartTc Device? 1 to 12, FrameMemory1Clip to
FrameMemory8Clip
Applicable device
MasterSnapshot Register? 1 to 99 Applicable register number
MasterTimelineRecall Register? 1 to 99 Applicable register number
RouterXpt DestinationButton? 1 to 128 Router cross-point button
Source? 1 to 1024 Router source number
Level? 1 to 8 Router level selection
PatternLimit ME? ME1, PP Control blocks on the applicable bank
Status? ToOn (a),
ToOff (b),
Any (c)
Pattern limit status
(a): Pattern limit applies
(b): Pattern limit does not apply
(c): The pattern limit status always changes
Symbol Parameter name Arguments Description
