Sample Waveform Library
D-10
VX4792 User Manual
Squared Sine Pulse
The Squared Sin Pulse waveform has the following characteristics:
H Waveform points: 1000
H Clock frequency: 100 MHz
H Output parameters: Filter 20 MHz
H Equation: range(0,3ms)<LF>0<LF>range(3ms,7ms)<LF>
(cos(2*pi*(x–0.5))+1)/2<LF>range(7ms,10ms)<LF>0
Figure D-8: Squared Sine Pulse
