Specifications
E-2
VX4792 User Manual
Table E-1: Electrical Characteristics
Characteristics Performance Requirement Supplemental Information
Power Requirements I
Pm
*1
I
Dm
*2
Typical Current
+5 V
-5.2 V
-2 V
+12 V
-12 V
+24 V
-24 V
7.8 A 1.20 A
4.4 A 0.12 A
2.2 A 0.06 A
0.4 A 0.02 A
0.3 A 0.03 A
0.3 A 0.04 A
0.2 A 0.08 A
7.1 A
4.0 A
2.0 A
0.3 A
0.2 A
0.3 A
0.2 A
VXI Interface
VXIbus Revision Level VXI System Specification Revision 1.3
Interface Type Message Based
Protocols Word Serial (WSP)
VXI Bus ECLTRG0Ć1 (Sync. Trigger)
LBUS0Ć11 (ECL Level)
Arbitrary Waveforms
Waveform Memory
Memory Length
Waveform Data 256 Kwords X 12 Bits
Marker 1 Data 256 Kwords X 1 Bit
Marker 2 Data 256 Kwords X 1 Bit
Waveform 64 to 256 K Points Multiple of 8
Sequence Memory 8 Kwords 32 bits per word
Scan Counter 1 to 64 K (16 Bits)
Sequence Memory 1 to 64 K (16 Bits)
Rate Clock
Frequency Range 10 Hz to 250 MHz
Accuracy
+10° C to +40° C 0.01%
+15° C to +30° C 0.005%
Resolution 0.1% to 0.01%
*1
Peak module current
*2
Dynamic module current
