Sony XVS-G1

131
2 Set the [Key Drop] button in the [Key Delay Mode]
group to the on state.
To set to key drop off mode, set the [Key Drop]
bu
tton to the off state.
3 Set 8H mode/4H mode using the [8H Mode] button.
On: 8H mo
de
Move the key fill/key source position downward
by
eight lines.
Off: 4H
mode
Move the key fill/key source position downward
by
four lines.
Setting the key delay mode
When frame delay mode is enabled, key drop is set to key
drop off mode (fixed) regardless of the key edge settings.
• The resizer function is used in frame delay mode.
Frame delay
mode is enabled only when the conditions
for use of the resizer are satisfied.
• When using dual resizer effects, frame delay mode is
disabled on
the two target keys.
• When frame delay mode is enabled, the video has a
one-frame delay.
1 Open the Home > M/E-1 > Key1 > Edge > Edge Type
Select menu (11101.21).
2 Enable/disable frame delay mode using the [Frame
Delay] button in the [Key Delay Mode] group.
On: Ena
ble frame delay mode.
Off: Di
sable frame delay mode.
Setting a Zabton
This section describes the M/E-1 key 1 menu as an
example.
When the edge type is emboss, a zabton cannot be set.
1 Open the Home > M/E-1 > Key1 > Edge > Edge Type
Select menu (11101.21).
2 Set the [Zabton] button to the on state and set the
following parameters.
Setting a zabton pattern
1 Open the Home > M/E-1 > Key1 > Edge > Zabton
Adjust menu (11101.23).
2 In the [Zabton Pattern] group, select a zabton pattern.
Key Wipe: Patt
ern for key wipe pattern key
Key Edge Pattern: Patt
ern for key edge color mix
Mask Pattern: Pattern for main mas
k source
3 Press the [Pattern Select] button.
A pattern selection window appears.
4 Set the button for the target pattern to the on state.
5 Press [OK].
6 Press the [Zabton Color] button and set the zabton
color using the following parameters.
To set modifiers for a zabton pattern
Pattern for key wipe pattern key:
Press the [Pattern Adjust] bu
tton, open the Home >
M/E-1 > Key1 > Transition > Wipe menu (11101.52),
and set modifiers.
For details about setting modifiers, see “Setting
Independent Key Transition Wipe Modifiers”
(page 158).
Pattern for key edge color mix:
Press the [Pattern Adjust] bu
tton, open the Home >
M/E-1 > Key1 > Edge > Matte Adjust menu
(11101.22), and set modifiers.
For details about setting modifiers, see “To set
modifiers for a color mi
x pattern” (page 125).
Pattern for main mask source:
Press the [Pattern Adjust] bu
tton, open the Home >
M/E-1 > Key1 > Mask menu (11101.31), and set
modifiers.
For details about setting modifiers, see “To set
modifiers for a mask pattern” (page 132).
Notes
Note
No. Parameter Adjustment
1 Size Pattern size
2 Soft Softness of the pattern
contour
3 Density Density
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3 Hue Hue
4 Density Density
No. Parameter Adjustment
