Sony XVS-G1

144
4 In the [Mosaic/Defocus Mode] group, select a signal
to which to apply the mosaic effect.
Video/Key: Vide
o signal and key signal
Video: Vide
o signal
When a video signal and key signal are selected for
mosaic
, crop and mask are disabled.
To make a mosaic look like a relief
Set the [Relief] button to the on st
ate and set the following
parameters.
Setting defocus
1 Open the Home > M/E-1 > Key1 > Resizer/Proc Key
> Enhanced Effect menu (11101.42).
2 Set the [Resizer] button to the on state.
3 Set the [Defocus] button to the on state and set the
following parameters.
4 In the [Mosaic/Defocus Mode] group, select a signal
to which to apply the defocus effect.
Video/Key: Vide
o signal and key signal
Video: Vide
o signal
When a video signal and key signal are selected for
defoc
us, crop and mask are disabled.
To remove the black level leakage that occurs at
t
he edges of the screen
Set the [Clean Defocus] butt
on to the on state.
Setting a mask
• When a video signal and key signal are selected for
resizer mosaic/defocus, mask is disabled.
• When a mask effect is applied to a border, the boundary
b
ecomes discontinuous, giving an unnatural effect.
Avoid applying a mask to a border.
1 Open the Home > M/E-1 > Key1 > Resizer/Proc Key
> Enhanced Effect menu (11101.42).
2 Set the [Resizer] button to the on state.
3 Set the [Dual Rszr Effect] button to the on state.
4 Set the [Mask] button to the on state.
5 In the [Mask Source] group, select a mask source.
Box: Box
Circle: Ci
rcle
Set the following parameters.
To rotate a mask pattern
In the [Rotation] group, select a rotation type.
Angle: Incline a pattern at a fixed angle.
Speed: Rotat
e a pattern at a fixed speed.
When the [Angle] button is selected, set the following
parameter.
2 Aspect Tile aspect ratio
• Negative values expand
vertically.
• Positive values expand
ho
rizontally.
Note
No. Parameter Adjustment
3 Gain Tile gain
4 Angle Light source direction
No. Parameter Adjustment
1 H Defocusing in ho
rizontal
direction
2 V Defocusing in ver
tical
direction
3 All Simultaneous defocusing
adjustment in horizontal
direction and vertical direction
Note
No. Parameter Adjustment
Notes
No. Parameter Adjustment
1 H Horizontal position
2 V Vertical position
3 Size Size
4 Soft Softness
5 Aspect Aspect ratio
No. Parameter Adjustment
1 Angle Inclination angle of pattern
• A value of –1.00 corresponds to
a rotation of
one turn
counterclockwise.
• A value of +1.00 corresponds to
a
rotation of one turn clockwise.
• A value of 0.00 corresponds to
n
o rotation.
