162
2
Press the [Current Pattern] button and enter a pattern
number in the numeric keypad window.
The icon for the selected wipe pattern is displayed on
t
he right side of the [Current Pattern] button.
Saving a wipe snapshot
Set a wipe and save a wipe snapshot register using the
following procedure.
1
Open the Home > M/E-1 > Bus/Transition > Wipe >
Wipe Snapshot menu (11109.37).
2
Press the [Store] button in the [Mode] group.
3
Press the button for the target register to save.
The register button is lit orange and the
wipe settings
are saved in the snapshot.
If you press a register button in which a wipe
snapsh
ot is already saved, the register data will be
overwritten.
Recalling a wipe snapshot
1
Open the Home > M/E-1 > Bus/Transition > Wipe >
Wipe Snapshot menu (11109.37).
2
Press the [Recall] button in the [Mode] group.
3
Press the button for the target register to recall.
The register button is lit orange and the wipe snapshot
i
s recalled.
Deleting a wipe snapshot
1
Open the Home > M/E-1 > Bus/Transition > Wipe >
Wipe Snapshot menu (11109.37).
2
Press the [Delete] button in the [Mode] group.
3
Press the button for the target register to delete.
The wipe snapshot is deleted and the register button
ch
anges to register number display.
Note
