You can select wipe snapshot registers (1 to 10) using the
buttons in the memory recall section.
The wipe pattern icon is displayed on buttons for registers
wi
th a registered snapshot.
The register number is displayed on buttons for registers
wi
thout a registered snapshot.
The wipe pattern number is displayed on the top right
butt
on in the memory recall section.
The button color varies as foll
ows, according to the
register state.
Gray characters: Register not c
ontaining a registered
snapshot
White icon/text: Register containing a registered snapshot
Lit orange: Last recalled register
• The register name is displayed instead of the wipe
p
attern icon on buttons for registers with a registered
snapshot. The register number is displayed if a register
name has not been configured.
For details about setting the bu
tton display, see
“Setting the button display in wipe snapshot operation
mode/DME wipe snapshot operation mode”
(page 414).
• When both the main pattern and sub pattern are selected
for a
pattern mix, the main pattern icon is displayed.
Selecting a wipe pattern
1 Press the [WIPE] button.
The memory recall section switches to wipe snapshot
op
eration mode.
2 Press the [PTN NO.] button.
The memory recall section switches to numeric
keyp
ad mode.
3 Enter a pattern number and press the [ENTER]
button.
The memory recall section returns to wipe snapshot
ope
ration mode. The selected pattern number is
displayed on the top right button in the memory recall
section.
Saving a wipe snapshot
Set a wipe and save a wipe snapshot register using the
following procedure.
1 Press the [WIPE] button.
The memory recall section switches to wipe snapshot
op
eration mode.
2 Press and hold the [WIPE] button and press the button
for the target register to save.
The register button is lit orange and the wipe settings
are saved in t
he snapshot.
If you press a register button in which a wipe
snapshot i
s already saved, the register data will be
overwritten.
Recalling a wipe snapshot
1 Press the [WIPE] button.
The memory recall section switches to wipe snapshot
operati
on mode.
2 Press the button for the target register to recall.
The register button is lit orange and the wipe snapshot
is rec
alled.
To undo a register recall
To undo a recall immediately
after recalling a register,
press the [UNDO] button.
Deleting a wipe snapshot
1 Press the [WIPE] button.
The memory recall section switches to wipe snapshot
operati
on mode.
2 Press and hold the [DEL] button and press the button
for the target register to delete.
The wipe snapshot is deleted and the register button
ch
anges to register number display.
Wipe Snapshot Operations (Menu)
The same memory recall buttons as in the memory recall
section of the Flexi Pad control block are displayed in the
Bus/Transition > Wipe > Wipe Snapshot menu on the
switcher bank. The settings and display of the memory
recall buttons in the Flexi Pad control block and in the
menu are linked.
This section describes the M/E-1 menu as an example.
Selecting a wipe pattern
1 Open the Home > M/E-1 > Bus/Transition > Wipe >
Wipe Snapshot menu (11109.37).
