Sony XVS-G1

216
This section describes setting a shadow on channel 1 as an
example.
1 Open the Home > DME > Global Effect > Shadow
menu (15109.31).
2 Set the [Ch 1 Shadow] button to the on state and set
the following parameters.
3 In the [Ch 1 Shadow Source] group, select a signal to
insert in the shadow.
Video: Ch
annel 2 input video signal
Flat Color: Si
ngle color
When the [Flat Color] button i
s selected, set the
following parameters.
To set a shadow on a channel other than channel 1, do the
foll
owing.
To set a shadow on channel 2:
Set using the [Ch 2 Shadow] button and [Ch 2
Shad
ow Source] group.
Channel 3 is used as the shadow.
To set a shadow on channel 3:
Set using the [Ch 3 Shadow] button and [Ch 3
Shad
ow Source] group.
Channel 4 is used as the shadow.
Setting a shadow using channels 1 to 3 (Ch1 +
Ch2 + Ch3)
Set a “Ch1 + Ch2 + Ch3” combine,
set the [Ch 1 + Ch 2
Shadow] button to the on state, and perform the
following.
To set a shadow on channel 1 for the background for the
images on
channels 1 and 3:
Set the [Ch 1 Shadow] button to the on state.
To set a shadow on channel 2 for the background for the
images on
channels 1 and 2:
Set the [Ch 2 Shadow] button to the on state.
Setting a shadow using channels 2 to 4 (Ch2 +
Ch3 + Ch4)
Set a “Ch2 + Ch3 + Ch4” combine,
set the [Ch 2 + Ch 3
Shadow] button to the on state, and perform the
following.
To set a shadow on channel 2 for the background for the
images on
channels 2 and 4:
Set the [Ch 2 Shadow] button to the on state.
To set a shadow on channel 3 for the background for the
images on
channels 2 and 3:
Set the [Ch 3 Shadow] button to the on state.
Setting a shadow using channels 1 to 4 (Ch1 +
Ch2 + Ch3 + Ch4)
Set a “Ch1 + Ch2 + Ch3 + Ch4” combine, set the [Ch 1 +
C
h 2 Shadow] button to the on state, and perform the
following.
To set a shadow on channel 1 for the background for the
images on
channels 1, 3, and 4:
Set the [Ch 1 Shadow] button to the on state.
To set a shadow on channel 2 for the background for the
images on
channels 1, 2, and 4:
Set the [Ch 2 Shadow] button to the on state.
To set a shadow on channel 3 for the background for the
images on
channels 1, 2, and 3:
Set the [Ch 3 Shadow] button to the on state.
To set a shadow for the background for t
he images on
channels 1 and 2:
Set the [Ch 1 Shadow] button and [Ch 3 Shadow]
button to the
on state.
Channel 3 is used as the shadow of channel 1, and
cha
nnel 4 is used as the shadow of channel 2.
Ch1 + Ch2,
Ch3 + Ch4
a – a – –
Ch1 + Ch2
+ Ch3
a a – a –
Ch2 + Ch3
+ Ch4
– a a – a
Ch1 + Ch2
+ Ch3
+
Ch4
a a a a –
No. Parameter Adjustment
1 Position H Shadow position in the
h
orizontal direction
2 Position V Shadow position in the
vertical direction
3 Density Density of shadow
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3 Hue Hue
Channel Shadow setting
Ch1 Ch2 Ch3 Ch1 + Ch2 Ch2 + Ch3
