Image creation operation
This section describes the operation of a switcher bank
shared between main and sub as an example.
To switch between main and sub, press the [MAIN]
bu
tton or [SUB] button in the cross-point control block.
You can also switch between main
and sub using the
[MAIN] button and [SUB] button in the transition control
block and transition control block (simple type).
1 Press the [MAIN] button, turning it on.
If the [SUB] button is lit, pre
ss the [SUB] button,
turning it off.
2 Create the main side image.
3 Press the [MAIN] button, turning it off.
4 Press the [SUB] button, turning it on.
5 Create the sub side image.
6 Press the [MAIN] button, turning it on.
Both the [MAIN] button and [SUB] button should be
tu
rned on.
When both the [MAIN] button and [SUB] button are
se
lected, the control panel shows the status of the
main side.
7 Execute a transition.
Both main side and sub side images are switched.
Multi Program 2 Mode Restrictions
In multi program 2 mode, settings and functions have the
following restrictions.
• A key wipe has the following restrictions.
– Only standard wipe patterns can be used
– Pattern mix cannot be used
– Split, pairing, modulation, spring, and spiral cannot
be used
– Edge fill color matte is flat color only
– Four types of multi replic
ation are available for
selection
• The key priority cannot be changed, depending on the
transit
ion.
• Transition preview cannot be used.
• DMEs can be used in up t
o two locations
simultaneously on main and sub.
– When using a DME wipe only
1-channel mode DME wipe: Can be used separately
o
n main and sub.
2-channel mode or 3-channel mode DME wipe: Can
be
used on either main or sub only.
– When using a processed key only
One DME channel: Can be used on two keys (main
an
d/or sub).
Two to four DME channels: Can be used on one key
(ma
in or sub).
– When using the image effect function
Can be used on two backgrounds (background A bus/
B b
us on main and/or sub).
• On a sub switcher bank, configuration data cannot be
co
pied or swapped.
• On a sub switcher bank, t
he “AUTO PVW” utility
command cannot be used.
• In the following cases, a tra
nsition using the fader lever
may not be performed correctly.
– When flip-flop mode/bus fixed mode are set
differently on
main and sub
– For 2-stroke operations, such as a pattern limit or
preset
color mix
• On a sub switcher bank, split faders cannot be used.
• When a snapshot/effect timeline is recalled
si
multaneously on main and sub, the following data is
reflected in the settings for main.
–Keys
– Switcher bank operation mode
– DME external video bus and utility 1 bus
• When a snapshot/effect timeline
is recalled which has a
different operation mode setting than the current
switcher bank operation mode, the following occurs.
– If the operation mode is not a target of the snapshot/
effe
ct timeline, the current operation mode
configuration is used.
– If the operation mode is a target
of the snapshot/effect
timeline, the operation mode configuration data
saved in the snapshot/effect timeline is applied and
then the other data is recalled.
• The settings of the [MACRO ATTACH ENABLE]
bu
tton/[MCRO ATTCH ENBL] button in the cross-
point control block are common to main and sub.
• The setting of the [SHOW KEY] button in the key
co
ntrol block is common to main and sub.
• On DME utility 1 bus and DME utility 2 bus cross-point
but
tons, it is not possible to set separate macro
attachments on main and sub.
• Link settings are maintained even when the swit
cher
bank operation mode is changed. Change the link
settings, as required.
