Key Control Block
The key control block is used to adjust and modify keys. For details, see “Chapter 6 Keys” (page 115).
a Delega
tion buttons
b D
ME channel buttons
Selects DME channels (DME1 to DME4) to assign to a
ke
y.
The DME channel buttons assigned to the selected key
are li
t green. The DME channel buttons assigned to other
keys/buses are lit amber.
While the [TRANS] button/[SUB TRANS] button is
sel
ected, you can assign a DME channel to use in a DME
wipe.
c O
n-air indicators
When a DME channel is used as an on-air image, the
corre
sponding indicator is lit red.
d S
etting buttons
Configures key settings.
Setting buttons for different fu
nctions are assigned to
three pages (1/3, 2/3, 3/3), where you can switch the page
by pressing the [PAGE] button.
You can check which functions are configured for the
butt
ons in the setting button display area.
Button
name
Description
M/E1 to
M/E5
P/P
Assigns a switcher bank (M/E-1 to M/E-5,
P/P) to the key control block.
KEY1 to
KEY8
• Assigns a key (key 1 to key 8) to the key
control bl
ock.
• You can press and hold an [M/E1] to
[M/E5] button or [P/P] button and then
press a [KEY1] to
[KEY8] button to return
the key settings to the initial settings.
TRANS • Used to check the DME channel used in a
transition.
• You can press and hold a [KEY1] to
[KEY8] button and
press the [TRANS]
button to check the DME channel used in
an independent key transition.
• While the [TRANS] button is selected, you
can press a [D
ME1] to [DME4] button to
assign a DME channel to use in a DME
wipe.
SUB
TRANS
Used as the [TRANS] button on the sub side
wh
en in multi program 2 mode.
