2 In the [Ref Output Format] group, select a reference
signal.
Tri Sync: H
D tri-level sync
BB: Black b
urst or sync
When the system signal format
is 720P and the input
reference signal is set to [Tri Sync], the black burst
field information generated by the switcher is used
when the output reference signal is set to [BB].
3 Press the [Apply] button in the [Signal Format/
Frequency/Ref] group.
To return to the previous setting
Press the [Clear] button in the [Signal Format/
Frequ
ency/Ref] group.
4 Check the message, then press [OK].
The switcher system reboots.
Setting the Image Switch Timing
1 Open the Home > Setup > System > Format/Config >
Format menu (19101.22).
2 In the [Switch Timing] group, select the switch
timing.
Any: No
t specified
Field1: Fi
eld 1
Field2: Fi
eld 2
When the system signal fo
rmat is 720P and the
frequency is 50, set to [Any] (fixed).
Setting the Reference Phase
1 Open the Home > Setup > System > Format/Config >
Format menu (19101.22).
2 Press the [System Phase] button and enter a reference
phase (microseconds) in the numeric keypad
window.
Setting the Dynamic Range
Setting the OETF and color space
You can select the OETF (Opto-Electronic Transfer
Function) and color space.
The combinations of signal formats and OETF/color
space that can
be selected are as follows.
• Correct operation may not occur for settings other than
t
he combinations above.
• Changing the OETF/color space settings may
moment
arily distort the image.
• When TIFF file/BMP file/TARGA file/PNG file
c
ontent is loaded into frame memory or an SL key, any
changes to the color space are not applied to the images.
To reflect the change in color space, unload and then
reload the content.
1 Open the Home > Setup > System > Format/Config >
HDR/SDR Format menu (19101.23).
2 In the [OETF] group, select an OETF.
SDR: SDR (Sta
ndard Dynamic Range)
HLG: HLG
(Hybrid Log Gamma)
PQ: PQ
(Perceptual Quantization)
S-Log3 (HDR): S-
Log3
S-Log3 (Live HDR): Dis
play with system gamma
added to S-Log3
3 In the [Color] group, select a color space.
BT.709: BT.
709 color space
BT.2020: B
T.2020 color space
Setting the input signal conversion mode
1 Open the Home > Setup > System > Format/Config >
HDR/SDR Format menu (19101.23).
Note
Note
Signal format OETF Color space
2160P SDR BT.709,
BT.2020
HLG, PQ, S-Log3
(HD
R), S-Log3 (Live
HDR)
BT.2020
1080P SDR BT.709
HLG, PQ, S-Log3
(HD
R), S-Log3 (Live
HDR)
BT.2020
1080i SDR BT.709
720P SDR BT.709
Notes
