In the list on the left, select the target port to set.
3
In the [TC Source] group, select a timecode source
(reference number for determining the tape position).
LTC:
Use LTC (Longitudinal Time Code).
When interpolation data is returned from
a VTR,
use that interpolation data.
LTC:VITC: No
rmally use LTC, except when the
tape is moving at speeds at which LTC cannot be
read, use VITC.
When interpolation data is returned from
a VTR,
use that interpolation data.
VITC: Use VIT
C (Vertical Interval Time Code).
CTL:
Use CTL (Control) pulse or timer counter
pulse.
Use this only for a tape on
which no timecode is
recorded.
4
In the list on the right, set the VTR constants of the
item.
Press the [Setting] button for an item to set and enter
a VTR co
nstant (00 to FF) in the numeric keypad
window.
Setting a Disk Recorder (VDCP)
1
Open the Home > Setup > External Device > Serial/
Net Port Setting > DDR VDCP menu (19105.63).
A list of ports is shown on the l
eft and the settings
status of the selected port is shown on the right.
2
In the list on the left, select the target port to set.
3
In the [DDR Type] group, select a type of disk
recorder.
Player: Pl
ayer
Recorder: Re
corder
4
In the [Name Mode] group, select a file name mode.
Fixed 8 Character: 8-c
haracter file name
Variable Length: Variable-length file name (up to
23
characters)
5
In the [Frame Control Mode] group, select a frame
control mode.
For a disk recorder that doe
s not support a timecode
with a drop frame bit, set drop frame mode or non
drop frame mode.
Drop Frame:
Drop frame mode
Non Drop Frame: N
on-drop frame mode
• Configurable only when the system signal format
fre
quency is 59.94.
• If the drop frame bit of the t
imecode is set, it
operates in drop frame mode.
6
In the [TC Sense] group, select a timecode sense
mode.
Zero based: T
imecode sense (detection), taking the
first frame of the loaded file as 00:00:00:00.
SOM based: Sense (dete
ction) occurs using the
timecode recorded in the loaded file.
7
Enable/disable duration detection using the [Duration
Sense] button.
On:
Enable duration sense (detection).
Off:
Disable duration sense (detection).
Item Item description
VTR Constant
Block1 Byte1
HI-BYTE (DEVICE TYPE)
VTR Constant
Block1 Byte2
LO-BYTE (DEVICE TYPE)
VTR Constant
Block1 Byte3
HI-BYTE (FRAME) (PREROLL
TIM
E)
VTR Constant
Block1 Byte4
LO-BYTE (FRAME) (P
REROLL
TIME)
VTR Constant
Block1 Byte5
EDIT DELAY (FRAME)
VTR Constant
Block1 Byte6
EE DELAY (FRAME)
VTR Constant
Block1 Byte7
OVER RUN (FRAME)
VTR Constant
Block1 Byte8
TRAJECTORY
VTR Constant
Block2 Byte1
TC READ DELAY (FRAME)
VTR Constant
Block2 Byte2
START DELAY (FRAME)
VTR Constant
Block2 Byte3
AFTER SYNC DELAY –
VTR Constant
Block2 Byte4
AFTER SYNC DELAY +
VTR Constant
Block2 Byte5
MODE1
VTR Constant
Block2 Byte6
MODE2
VTR Constant
Block2 Byte7
MAX PRRL SPEED
VTR Constant
Block2 Byte8
QUICK PVW PRRL TIME (FRAME)
