When second delegation mode is disabled
In a 36-button row, the butto
n numbers are as follows.
The rightmost (36th) button is
used as the [SHIFT]
button.
When selecting the bus/signal of button numbers 1 to 35
in the 1st row
and 3rd row, press the corresponding
number button.
When selecting the bus/signal of button numbers 36 to 70
in
the 2nd row and 4th row, press the corresponding
number button.
When selecting the bus/signal of button numbers 36 to 70
in the 1st row
and 3rd row, press and hold the [SHIFT]
button and press the corresponding number button.
[SHIFT] button
The [SHIFT] button has two operation modes.
Hold mode: Mode where the shifted sta
te is selected
while the button is pressed
Lock mode: Mode where every time the button is pressed,
i
t toggles between the shifted state and unshifted state
In cross-point button rows (3rd row/4th row)
, you can
also disable the shift button function.
For details about setting delegation button rows, see
“Setting the operation mode of the shift button”
(page 404).
For details about setting cross-point button rows,
see
“Setting the [SHIFT] button operation mode”
(page 380).
• When second delegation is disabled, the 1st row and 3rd
row shift
buttons are set to hold mode (fixed). You can
select the button number in the shifted state while
pressing the shift button.
The 2nd row and 4th row are always in the shifted state,
h
ence the shift buttons cannot be operated.
• The rightmost button operates as a cross-point button
wh
en the [SHIFT] button use is disabled in the cross-
point button row.
In a 36-button row, it becomes button number 36.
Cross-Point Button Display
Source name of signals
You can attach a name (source name) to the signal
assigned to a cross-point button, with a maximum of 16
characters.
The specified source name appear
s on the display of the
cross-point control block/AUX bus control block (AUX
bus operation mode). When a signal in the shifted state of
a cross-point button is selected, the source name of the
shifted-state signal is displayed.
Six types of display mode can be set according to the
info
rmation to display. The display mode can be switched
using the following buttons.
• ICP-X7000: Select display mode 1 to 6 using the
display mo
de buttons assigned to the cross-point pad.
• ICP-X1000 series: The displ
ay mode switches each
time the [DISP MODE] button assigned to the function
button section is pressed.
Colors of lit cross-point buttons
In a single cross-point button row, only the last pressed
button is active, and is lit amber or red.
When second delegation mode is enabled on the AUX bus
co
ntrol block, 4th row cross-point buttons are lit green in
the low tally state.
Cross-point indicators
When lit, these indicate the source color of the video
signal assigned to buttons on the 3rd row of the cross-
point control block/AUX bus control block (AUX bus
operation mode).
The color of the cross-point indic
ators does not change
even if a 3rd row button is lit red or amber.
Cross-Point Hold
Setting cross-point hold enables you to recall an effect
timeline or snapshot while keeping the current cross-point
selection unchanged.
Button Button number
when the [SHIFT]
button is off
Button number
when the [SHIFT]
button is on
1st row and 3rd
row:
1st (left side) to
35
th buttons
1 to 35 36 to 70
2nd row and 4th
row:
1st (left side) to
35th buttons
– 36 to 70
Notes
Color of
button when
lit
Button state
Amber Low tally
Selected signal is not included in the final
output image
Red High tally
Selected signal is included in the final
ou
tput image
Note
