Speco D12LX - Specifications

Operation Instruction
96
Specifications
VIDEO
Signal Format NTSC or PAL (Auto Detect)
Video Input
Local Composite: 8 or 16 looping inputs, 1 Vp-p, auto-terminating, 75 Ohms
Network 4 network devices (100Mbps/1Gbps Ethernet)
Monitor Outputs
HDMI: 1 HDMI
VGA: 1
SPOT: 1 BNC, 1 Vp-p, 75 Ohms
Video Resolution
HDMI/VGA: 1920x1080p, 1920x1080i, 1280x1024, 1024x768
Composite (SPOT): 704x480 (NTSC), 704x576 (PAL)
Record Speed
(images per second)
Real-time: 480ips (NTSC), 400ips (PAL) @ 4CIF/960H (16-ch Model)
Real-time: 240ips (NTSC), 200ips (PAL) @ 4CIF/960H (8-ch Model)
Network Device: 70ips @ 1920x1080 / 120ips @ 1280x720
Playback Speed
(images per second)
Full Duplex: 240ips (NTSC), 200ips (PAL) @ 4CIF/960H (16-ch Model)
Full Duplex: 120ips (NTSC), 100ips (PAL) @ 4CIF/960H (8-ch Model)
INPUTS/OUTPUTS
Alarm Input 8 or 16 terminal, programmable as NC or NO, 2.4V (NC) or 0.3V (NO) threshold, 5VDC
Alarm Output 2 relay output, programmable as NC or NO, 2A@125VAC, 1A@30VDC
Alarm Reset Input 1 TTL, terminal block
Internal Buzzer 80dB at 10cm
Network Connectivity 10Mbps/1Gbps Ethernet (RJ-45)
Audio Input
Local RCA Input, 4 Line In
Network 4, 100Mbps/1Gbps Ethernet
Audio Output RCA Output: 1, Line Out
Text Input POS Interface, ATM Interface
CONNECTORS
Video Input
Local Composite: 8 or 16 BNC
Network RJ-45 (100Mbps/1Gbps Ethernet)
Video Loop Composite: 8 or 16 BNC (Auto Terminating)
Monitor Output
HDMI: 1 HDMI
VGA: 1 VGA
SPOT (Composite): 1 BNC
Audio In
Local 4 RCA connector
Network RJ-45 (100Mbps/1Gbps Ethernet)
Audio Out 1 RCA connector
Alarm Input/Output Terminal Blocks
Ethernet Port 1 RJ-45
eSATA Port eSATA
RS232C Serial Port DB9 (P)
RS485 Serial Port Two-connector terminal block
IR Port 1 Remote Control
USB Port 2 (USB 2.0)
STORAGE
Primary Storage SATA hard disk drive (up to 4) (up to 3 with an internal DVD RW drive)
Secondary Storage*
eSATA hard disk drive (RAID)
Built-in DVD RW drive
USB hard disk drive or flash drive
* When installing an internal DVD RW drive, connect the SATA I/O cable to the SATA ODD socket.
