Speco D12LX - Remote Control Buttons; ID Button; Camera Buttons; Sequence Button

Operation Instruction
10
Remote Control Buttons
ID Button
Camera Buttons
Sequence Button
Login/Logout Button
Arrow Buttons
Menu Button
Playback Buttons
Alarm Button
Layout Button
Zoom Button
PTZ Button
Enter Button
Esc Button
PTZ Control Buttons
Copy Button
Play/Stop Button
Figure 4 : Infrared remote control.
NOTE: For simplicity, the button descriptions in this manual refer to the front panel buttons.
ID Button
If a DVR System ID is set to 0, the infrared remote control will control that DVR without any additional operations.
(Refer to the System General setup screen in this chapter for further information on setting the System ID.) If the system
ID is 1 to 16, you must to press the ID button and then press the number button (1 to 16 (+10 & 6)) in order to control
that DVR. If the System ID of two or more DVRs is set to 0, those DVRs will react to the infrared remote control at
the same time.
Camera Buttons
Pressing the individual camera buttons will cause the selected camera to display full screen. Buttons 1 to 9 are also
used to enter passwords.
Sequence Button
When in the Live Monitoring mode, pressing the SEQUENCE button displays live channels sequentially.
Login/Logout Button
Pressing the
LOGIN/OUT button displays the Login or Logout screen.
